Toyota Prius I facelift (2000-2003) right front door lock control switch Wiring diagrams
This page contains all the electrical diagrams for the component. right front door lock control switch, in which he is found in the car Toyota Prius I facelift (2000-2003). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right front door lock control switch (1 of 3)
BDR
BLK/RED WIRE
BLK/WHT WIRE
BLU/BLK WIRE
BLU/YEL WIRE
BODY ECU
DCTY
DOME FUSE
DOOR FUSE
ECU-B FUSE
ENGINE HOOD COURTESY SWITCH (NEAR HOOD LATCH)
ENGINE ROOM J/B (ON LEFT SIDE OF ENGINE COMPT)
GAUGE FUSE
GRN WIRE
GRN/BLK WIRE
HORNS SYSTEM
HOT AT ALL TIMES
HOT IN RUN OR START
IMMOBILIZER CIRCUIT
IND
INSTRUMENT PANEL J/B
INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH)
J/C 1 (LEFT END OF DASH)
J/C 11 (BEHIND LEFT END OF DASH)
J/C 14, J/C 15 (BEHIND UPPER RIGHT SIDE OF DASH)
J/C 17 (BEHIND UPPER RIGHT SIDE OF DASH)
J/C 26 (BEHIND UPPER LEFT CENTER OF DASH)
J/C 27 (BEHIND UPPER LEFT CENTER OF DASH)
J/C 27, J/C 28 (BEHIND UPPER LEFT CENTER OF DASH)
J/C 33
LEFT "C" PILLAR)
LEFT REAR DOOR LOCK UNIT
LOCK
LSWP
LT GRN/BLK WIRE
LUG
LUGGAGE COMPARTMENT DOOR KEY UNLOCK SWITCH
OBDII FUSE
PCTY
RCTY
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT FRONT DOOR LOCK CONTROL SWITCH
RIGHT REAR DOOR LOCK UNIT
THEFT DETERRENT HORN (BEHIND RIGHT HEADLIGHT)
UNLK
UNLOCK WARNING SWITCH
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Forced entry circuit (1 of 2) -> RIGHT FRONT DOOR LOCK CONTROL SWITCH
Wiring diagram right front door lock control switch (2 of 3)
A/C AMPLIFIER
AIR BAG SENSOR ASSEMBLY
BODY ECU
BRAKE ECU
CIGARETTE LIGHTER
COMBINATION SWITCH
CRUISE CONTROL SWITCH
DATA LINK CONNECTOR 3
DAYTIME RUNNING LIGHT RELAY
EMPS ECU
EOM
FRONT WIPER/ WASHER SWITCH
FUEL SENDER
GATEWAY ECU
HAZARD WARNING SWITCH
HYBRID VEHICLE CONTROL ECU
INSTRUMENT PANEL J/B
J/C 10 (ON LEFT END OF DASH)
J/C 11 (BEHIND LEFT END OF DASH)
J/C 17 (BEHIND UPPER RIGHT SIDE OF DASH)
J/C 18, J/C 19 (BEHIND RIGHT END OF DASH)
J/C 21 (BEHIND RIGHT END OF DASH)
J/C 22, J/C 23 (BEHIND UPPER LEFT SIDE OF DASH)
J/C 24, J/C 25 (BEHIND UPPER LEFT CENTER OF DASH)
KEY INTERLOCK SOLENOID
LEFT BUCKLE SWITCH, TENSION REDUCER
LEFT FRONT DOOR LOCK UNIT
LIGHT CONTROL RHEOSTAT
PARK/ NEUTRAL POSITION SWITCH
POWER WINDOW MASTER SWITCH
PTC HEATER
RELAY
REMOTE CONTROL MIRROR SWITCH
RIGHT BUCKLE SWITCH, SEAT BELT WARNING OCCUPANT DETECTION SENSOR
RIGHT FRONT DOOR LOCK CONTROL SWITCH
RIGHT FRONT DOOR LOCK UNIT TURN SIGNAL FLASHER RELAY TURN SIGNAL SWITCH
RIGHT REAR DOOR LOCK UNIT RIGHT FRONT POWER WINDOW CONTROL SWITCH
RIGHT REAR POWER WINDOW CONTROL SWITCH FUEL PUMP
SHIFT LOCK ECU
TRANSPONDER KEY COMPUTER
UNLOCK WARNING SWITCH
WHT/BLK WIRE
WIRELESS DOOR CONTROL RECEIVER
Go to component -> Ground distribution circuit (2 of 3) -> RIGHT FRONT DOOR LOCK CONTROL SWITCH
Wiring diagram right front door lock control switch (3 of 3)
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BLU/YEL WIRE
BODY ECU
DCTY
DOME FUSE
DOOR FUSE
ECU-B FUSE
ENGINE ROOM J/B (ON LEFT SIDE OF ENGINE COMPT)
GAUGE FUSE
GRN WIRE
GRN/BLK WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
INSTRUMENT PANEL J/B
INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH)
J/C 11 (BEHIND LEFT END OF DASH)
J/C 14, J/C 15 (BEHIND UPPER RIGHT SIDE OF DASH)
J/C 17 (BEHIND UPPER RIGHT SIDE OF DASH)
J/C 22 (BEHIND UPPER LEFT SIDE OF DASH)
J/C 24, J/C 25 (BEHIND UPPER LEFT CENTER OF DASH)
J/C 27 (BEHIND UPPER LEFT CENTER OF DASH)
LEFT "C" PILLAR)
LEFT REAR DOOR LOCK MOTOR, DOOR UNLOCK DETECTION SWITCH
LOCK
LSWP
LUG
PCTY
RCTY
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT FRONT DOOR LOCK CONTROL SWITCH
RIGHT REAR DOOR LOCK MOTOR, DOOR UNLOCK DETECTION SWITCH
UNLK
UNLOCK WARNING SWITCH
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Power door lock circuit (1 of 2) -> RIGHT FRONT DOOR LOCK CONTROL SWITCH
