Toyota Prius I facelift (2000-2003) rf cf wp ne act htro Wiring diagram
This page shows the only wiring diagram for the component.rf cf wp ne act htro, which is found in the car Toyota Prius I facelift (2000-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rf cf wp ne act htro (1 of 1)
A/C
A/C AMPLIFIER (BEHIND CENTER OF DASH)
A/C MAGNETIC CLUTCH, LOCK SENSOR (LEFT FRONT OF ENGINE)
A/C SOLAR SENSOR (BEHIND TOP RIGHT SIDE OF DASH)
AIR INLET CONTROL SERVO MOTOR (BEHIND RIGHT SIDE OF DASH)
AIR MIX CONTROL SERVO MOTOR (BEHIND LEFT CENTER OF DASH)
AIR VENT MODE CONTROL SERVO MOTOR (BEHIND LEFT CENTER OF DASH)
AMH AMC SGTP TP
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BLU/YEL WIRE
BLW
BODY ECU
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
BSET TSET MSET
CLR MG RELAY
ECU-B FUSE
ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT)
F/R LED RDEF
F/R SW RDEF
FULL
GAUGE FUSE
GND B+
GRN WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HTR FUSE
HTR RELAY
IDH MPX+
INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH) HTR FUSE
J/C 1 (BEHIND LEFT END OF DASH)
J/C 11
J/C 2, J/C 3 (BEHIND UPPER LEFT END OF DASH)
J/C 22, J/C 23 (BEHIND LEFT SIDE OF DASH)
J/C 24, J/C 25 (LEFT CENTER OF DASH)
J/C 27 (BEHIND LEFT CENTER OF DASH)
LOCK MGC PSW
LT GRN WIRE
LT GRN/RED WIRE
ORG/ WIRE
PIG A/C
PNK WIRE
PNK/BLK WIRE
PNK/GRN WIRE
PSG
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RF CF WP NE ACT HTRO
SGLOCK
TE SGTE SGTR TR TS
TPI SGTPI AIR AIF
TPM SGTPM AOF AOD
VIO WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Automatic a/c circuit (1 of 2) -> RF CF WP NE ACT HTRO
