Back door opener circuit for Toyota Prius C I facelift (2014-2020)
Back door opener circuit
BACK DOOR LOCK ASSEMBLY
BACK DOOR OPENER SWITCH ASSEMBLY
BK/DR RELAY
BLK WIRE
BLU WIRE
BRN WIRE
CERTIFICATION ECU
COMPUTER DATA LINES SYSTEM
COURTESY
COWL SIDE J/B 1
COWL SIDE J/B 2
CSEL
CUTB
D/L FUSE
DATA
ECU-B 1 FUSE
ENGINE ROOM R/B 2
GRN WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL J/B ASSEMBLY
LEFT "C" PILLAR)
LOCK
LT GRN WIRE
MAIN BODY ECU
PNK WIRE
PPL/PNK WIRE
RCO
RDAM
RED WIRE
SWITCH
TIRE PRESSURE WARNING ECU, RECEIVER
VIO WIRE
W/ SMART KEY
W/O SMART KEY SYSTEM W/ SMART KEY SYSTEM
WHT WIRE
WHT/BLK WIRE
YEL WIRE
