Cruise control circuit for Toyota Prius C I facelift (2014-2020)
Cruise control circuit (1 of 2)
ABS 2 FUSE
BLK WIRE
BLU WIRE
BRAKE PEDAL STROKE SENSOR ASSEMBLY
BRN WIRE
COMPUTER DATA LINES SYSTEM
EFI MAIN FUSE
EFI MAIN RELAY
ENGINE ROOM J/B 2
ENGINE ROOM R/B 2
FR- PNK FR+ WIRE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT SPEED SENSOR
LEFT REAR SPEED SENSOR
NCA WIRE
PNK WIRE
RED WIRE
RIGHT FRONT SPEED SENSOR
RIGHT REAR SPEED SENSOR
SKG
SKID CONTROL ECU W/ ACTUATOR (BRAKE BOOSTER W/ MASTER CYLINDER ASSEMBLY)
SKS
THROTTLE BODY ASSEMBLY W/ MOTOR
VCSK
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Cruise control circuit (2 of 2)
+RES -SET
ACCELERATOR PEDAL SENSOR ASSEMBLY
BLK WIRE
BLU WIRE
BRN WIRE
BUZZER
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
CONTROLLER
CRUISE CONTROL MAIN SWITCH (IF EQUIPPED)
CRUISE IND
ECU-B 2 FUSE
ENGINE ROOM R/B 2
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HYBRID VEHICLE CONTROL ECU
INSTRUMENT PANEL J/B ASSEMBLY
METER FUSE
ON OFF
ORG/ WIRE
OUT GND
PNK WIRE
RED WIRE
SET IND
SKID CONTROL ECU W/ ACTUATOR (BRAKE BOOSTER W/ MASTER CYLINDER ASSEMBLY)
SPIRAL CABLE SUB-ASSEMBLY W/ SENSOR
STOP FUSE
STOP LIGHT SWITCH ASSEMBLY
STP VPA
VIO WIRE
W/O PRE-COLLISION SYSTEM
WHT WIRE
WHT/BLK WIRE
YEL WIRE
