Back-up lamps circuit for Toyota Paseo L50 (1996-1999)
Back-up lamps circuit
A/T M/T
BACK-UP LIGHT SWITCH (PARK/NEUTRAL SWITCH W/ A/T) (TOP OF TRANSAXLE)
DRIVER'S SIDE J/B (LEFT KICK PANEL)
GAUGE FUSE
HOT IN ON AND START
J/C 5 (RIGHT SIDE OF DASH)
LEFT BACK- UP LIGHT (LEFT REAR COMBINATION LIGHT)
RED/BLK WIRE
RED/BLU WIRE
RIGHT BACK- UP LIGHT (RIGHT REAR COMBINATION LIGHT)
WHT/BLK WIRE
