Toyota Paseo L50 (1996-1999) right headlight, high beam indicator light, combination switch Wiring diagram
This page shows the only wiring diagram for the component.right headlight, high beam indicator light, combination switch, which is found in the car Toyota Paseo L50 (1996-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right headlight, high beam indicator light, combination switch (1 of 1)
ABS FUSE OBD-2 FUSE
ABS RELAY DATA LINK CONNECTOR 3
ALT-S FUSE MAIN FUSE
ALTERNATOR
ALTERNATOR STARTER, STARTER RELAY
BATTERY
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BLU/YEL WIRE
CANADA
CIG/ RADIO FUSE IGN FUSE
CIGARETTE LIGHTER
DEF FUSE
DOME FUSE
DRIVER'S SIDE J/B (LEFT KICK PANEL)
DRL FUSE
ECU/IG FUSE
EFI FUSE
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPARTMENT)
FRONT WIPER AND WASHER SWITCH
FRONT WIPER MOTOR WASHER MOTOR
FUSE
FUSIBLE LINK BLOCK (CENTER OF LEFT FENDER) ALT FUSE
GRN WIRE
GRY WIRE
HAZ-HORN FUSE
HEAD RELAY
IGNITION SWITCH
LEFT HEAD FUSE
LEFT HEADLIGHT, HIGH BEAM INDICATOR LIGHT, COMBINATION SWITCH
MAIN FUSIBLE LINK (14 GA-
OFF
OFF ON
ORG/ WIRE
POWER FUSE (CENTER OF DASH)
PPL
REAR WINDOW DEFOGGER RELAY, REAR WINDOW DEFOGGER
RED WIRE
RIGHT HEAD FUSE DIMMER FUSE
RIGHT HEADLIGHT, HIGH BEAM INDICATOR LIGHT, COMBINATION SWITCH
SRS FUSE
STOP FUSE
TO DIMMER RELAY (DIAGRAM 2 OF 2)
TO DRIVER'S SIDE J/B (DIAGRAM 2 OF 2) GAUGE FUSE
TO ENGINE ROOM R/B (DIAGRAM 2 OF 2)
TURN FUSE
USA
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
WHT/RED WIRE
WIPER FUSE
YEL WIRE
Go to component -> Power distribution circuit (1 of 2) -> RIGHT HEADLIGHT, HIGH BEAM INDICATOR LIGHT, COMBINATION SWITCH
