Toyota Paseo L50 (1996-1999) right door unlock detection switch Wiring diagram
This page shows the only wiring diagram for the component.right door unlock detection switch, which is found in the car Toyota Paseo L50 (1996-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right door unlock detection switch (1 of 1)
A/C AMPLIFIER
A/T
ABS ECU
AIRBAG SENSOR ASSEMBLY
BLOWER RESISTOR
BLOWER SWITCH
CANADA ONLY
CLOCK
CRUISE CONTROL ECU
CRUISE CONTROL SWITCH
DATA LINK CONNECTOR 3
DOOR LOCK CONTROL RELAY
FUEL PUMP
HEATER RELAY
HIGH MOUNT STOP LAMP
J/B 1 (LEFT KICK PANEL) INTEGRATION RELAY
J/C 2 (LEFT SIDE OF DASH)
J/C 3 (CENTER OF DASH)
KEY INTERLOCK SOLENOID
LEFT BUCKLE SWITCH CIGARETTE LIGHTER
LEFT DOOR KEY LOCK AND UNLOCK SWITCH
LEFT DOOR UNLOCK DETECTION SWITCH
LEFT LICENSE PLATE LAMP RIGHT LICENSE PLATE LAMP
LEFT REAR COMBINATION LAMP
LUGGAGE COMPARTMENT KEY UNLOCK SWITCH
MAIN DAYTIME RUNNING LAMP RELAY
O/D MAIN SWITCH
POWER MAIN RELAY
REAR WINDOW DEFOGGER SWITCH
RIGHT DOOR KEY LOCK AND UNLOCK SWITCH
RIGHT DOOR LOCK CONTROL SWITCH
RIGHT DOOR UNLOCK DETECTION SWITCH
RIGHT REAR COMBINATION LAMP
SHIFT LOCK ECU
THEFT DETERRENT AND DOOR LOCK CONTROL ECU
THEFT DETERRENT ECU
W/ REAR SPOILER
W/O REAR SPOILER
WHT/BLK WIRE
Go to component -> Ground distribution circuit (2 of 2) -> RIGHT DOOR UNLOCK DETECTION SWITCH
