Toyota Paseo L50 (1996-1999) hot w/light control switch in tail or head position Wiring diagram
This page shows the only wiring diagram for the component.hot w/light control switch in tail or head position, which is found in the car Toyota Paseo L50 (1996-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot w/light control switch in tail or head position (1 of 1)
BLK WIRE
BLU WIRE
BLU/YEL WIRE
BUZZER
CIG/ RADIO FUSE
COMBINATION METER
CONVERTIBLE COUPE
DOME FUSE
DRIVER SIDE J/B (LEFT KICK PANEL)
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPARTMENT)
GAUGE FUSE
GRN WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
HOT W/LIGHT CONTROL SWITCH IN TAIL OR HEAD POSITION
INTEGRATION RELAY
J/C 3 (BEHIND CENTER OF I/P)
LEFT BUCKLE SWITCH (IN DRIVER'S SEAT BELT BUCKLE)
LEFT DOOR COURTESY SWITCH (IN LEFT "B" PILLAR)
LT GRN WIRE
LT GRN/BLK WIRE
PNK WIRE
RED WIRE
RED/BLU WIRE
RICAN, CANADIAN MODELS
SEAT BELT
SEAT BELT RETRACTOR SWITCH (LEFT "B" PILLAR)
SOLID STATE
TAIL FUSE
UNLOCK WARNING SWITCH (ON STEERING COLUMN)
WHT WIRE
YEL WIRE
Go to component -> Warning system circuits -> HOT W/LIGHT CONTROL SWITCH IN TAIL OR HEAD POSITION
