Supplemental restraint circuit for Toyota Paseo L40 (1991-1996)

1 2 +SR -SR 1 2 -SL +SL 12 15 AB TC AIRBAG SQUIB (IN STEERING COLUMN) BLK WIRE BLK/ORG WIRE BLK/YEL WIRE BLU WIRE CENTER AIRBAG SENSOR ASSEMBLY (UNDER FRONT END OF CENTER CONSOLE) CIG FUSE COMBINATION METER CONN A CONN B CONN C CONNECTION DETECTION PIN DATA LINK CONNECTOR 1 (CHECK CONNECTOR) (LEFT REAR CORNER OF ENGINE COMPARTMENT) ECU-B FUSE FUSE BOX NO.2 (LEFT SIDE OF I/P) GRN WIRE HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START IGN FUSE J/C 1 (LEFT SIDE OF I/P) J/C 3 (BEHIND CENTER OF I/P) LA D- D+ TC LEFT FRONT AIRBAG SENSOR (LEFT SIDE OF ENGINE COMPARTMENT) ORG/ WIRE PNK WIRE PNK/BLU WIRE R/B 2 (LEFT SIDE OF ENGINE COMPARTMENT) RED WIRE RIGHT FRONT AIRBAG SENSOR (RIGHT SIDE OF ENGINE COMPARTMENT) SRS WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
