Toyota Paseo L40 (1991-1996) gauge fuse stop fuse Wiring diagram
This page shows the only wiring diagram for the component.gauge fuse stop fuse, which is found in the car Toyota Paseo L40 (1991-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram gauge fuse stop fuse (1 of 1)
-SL +SL
1995 VFTC
BLK WIRE
BLU WIRE
BLU/BLK WIRE
CANADA
CANADA USA
CIG FUSE
GAUGE FUSE STOP FUSE
GEAR SELECTOR)
GRN WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES HOT IN ON OR START
HOT IN ACC OR ON
J/B 1 (LEFT KICK PANEL)
J/C 1 (BEHIND LEFT SIDE OF I/P)
J/C 2 (BEHIND LEFT SIDE OF I/P)
J/C 3 (BEHIND CENTER OF I/P)
J/C 4 (BEHIND LEFT SIDE OF I/P)
J/C 5 (BEHIND CENTER OF I/P)
KEY INTERLOCK SOLENOID (ON STEERING COLUMN, ON IGNITION LOCK ASSEMBLY)
KLS+
PNK/BLU WIRE
RED WIRE
RED/BLU WIRE
SHIFT LOCK CONTROL SWITCH
SHIFT LOCK ECU (UNDER CENTER CONSOLE, BEHIND
SHIFT LOCK SOLENOID
STOP LIGHT SWITCH (BEHIND LEFT SIDE OF I/P)
TIMER (SOLID STATE)
USA
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Shift interlock circuit -> GAUGE FUSE STOP FUSE
