1.8l, cooling fan circuit for Toyota Matrix E140 (2008-2014)

43 8 9 RFC CANH CANL BLK WIRE BLU/BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM COOLING FAN ECU (LEFT REAR OF RADIATOR) DRIVER SIDE J/B (LEFT END OF DASH) E.F.I. ENGINE COOLANT TEMPERATURE SENSOR (REAR OF ENGINE) ECM (LEFT SIDE OF ENGINE COMPT) ECU- IG 1 FUSE ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) FAN 1 RELAY HOT AT ALL TIMES ENGINE ROOM J/B RDI FAN FUSE (LEFT SIDE OF ENGINE COMPT) RED/GRN WIRE RELAY ENERGIZED WHT WIRE WHT/BLK WIRE YEL WIRE
