Toyota Matrix E140 (2008-2014) main body ecu pws altb Wiring diagram
This page shows the only wiring diagram for the component.main body ecu pws altb, which is found in the car Toyota Matrix E140 (2008-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram main body ecu pws altb (1 of 1)
ALT FUSE
BLK WIRE
BLU WIRE
BRN WIRE
DOOR FUSE
DOOR LOCKS SYSTEM
DOWN
DRIVER SIDE J/B (LEFT END OF DASH)
ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT)
F/R DOOR FUSE
GRN WIRE
HOT AT ALL TIMES
LEFT FRONT DOOR COURTESY LIGHT SWITCH (LEFT "B" PILLAR)
LEFT FRONT DOOR WINDOW REGULATOR SUB ASSEMBLY (DRIVER'S DOOR)
LEFT REAR POWER WINDOW REGULATOR
LEFT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY
MAIN BODY ECU PWS ALTB
MOTOR (LEFT REAR DOOR)
ORG/ WIRE
PCTY DCTY
PNK 3 WIRE
PNK WIRE
POWER FUSE
POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY
PWR RELAY
R/L DOOR FUSE
R/R DOOR FUSE
RED WIRE
RIGHT FRONT DOOR COURTESY LIGHT SWITCH (RIGHT "B" PILLAR)
RIGHT FRONT DOOR WINDOW REGULATOR SUB ASSEMBLY (FRONT PASSENGER'S DOOR)
RIGHT FRONT POWER WINDOW REGULATOR SWITCH ASSEMBLY
RIGHT REAR POWER WINDOW REGULATOR MOTOR (RIGHT REAR DOOR)
RIGHT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY
UP DOWN
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Power windows circuit -> MAIN BODY ECU PWS ALTB
