Toyota Matrix E140 (2008-2014) electronic exterior power lights steering system system wiring diagram
This page shows the only wiring diagram for the component.electronic exterior power lights steering system system, which is found in the car Toyota Matrix E140 (2008-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
electronic exterior power lights steering system system wiring diagram (1 of 1)
1.8L 2.4L
2.4L 1.8L
ABS 3 FUSE ABS 1 FUSE
ACC CUT RELAY (1.8L)
AIR CONDITIONING SYSTEM
AIR CONDITIONING, ANTI-THEFT SYSTEMS
ALT FUSE
ALT-S FUSE
ANTI-LOCK BRAKES SYSTEM
BATTERY
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/YEL WIRE
C/OPN RELAY
CDS FAN FUSE RDI FAN FUSE
COOLING FANS SYSTEM
DCC SHORT PIN
DIMMER RELAY
DOME FUSE RAD 1 FUSE
ECU-B FUSE
EFI MAIN FUSE
ELECTRONIC EXTERIOR POWER LIGHTS STEERING SYSTEM SYSTEM
ENGINE CONTROLS SYSTEM
ENGINE CONTROLS, TRANSMISSIONS SYSTEMS
ETCS FUSE
FROM
FROM ABS 3 FUSE (DIAGRAM 1 OF 3)
FUSE
FUSE (1.8L)
FUSE (DIAGRAM 1 OF 3)
FUSE EFI MAIN RELAY
FUSIBLE LINK MAIN (12 GA-
GRN WIRE
GRY WIRE
H-LP MAIN FUSE HORN FUSE
H-LP RELAY
HORN RELAY
HTR FUSE
HTR SUB 3 FUSE HTR SUB 1 FUSE
IGN FUSE
INSTRUMENT CLUSTER, INTERIOR LIGHTS, ANTI-THEFT, DOOR LOCKS SYSTEMS
MAIN BODY ECU
METER FUSE
PNK WIRE
PWR OUTLET/ INVERTER FUSE
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RELAY
SOUND SYSTEMS
STARTING/ CHARGING SYSTEM
STARTING/ TO CHARGING IGNITION SYSTEM SWITCH (DIAGRAM 2 OF 3)
SUPPLEMENTAL RESTRAINTS, WARNING SYSTEMS
TO DRIVER SIDE J/B (DIAGRAM 3 OF 3)
TO ENGINE IGNITION CONTROLS SWITCH SYSTEM (DIAGRAM 2 OF 3)
TO H-LP MAN FUSE (DIAGRAM 1 OF 3)
TO IGNITION SWITCH (DIAGRAM 2 OF 3)
TO INVERTER RELAY (DIAGRAM 3 OF 3)
TO TO IGNITION FUSE SWITCH (DIAGRAM (DIAGRAM 2 OF 3) 2 OF 3)
TURN- HAZ FUSE EPS FUSE P/I FUSE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Power distribution circuit (1 of 3) -> ELECTRONIC EXTERIOR POWER LIGHTS STEERING SYSTEM SYSTEM
