Toyota Matrix E140 (2008-2014) canl tc ts Wiring diagram
This page shows the only wiring diagram for the component.canl tc ts, which is found in the car Toyota Matrix E140 (2008-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram canl tc ts (1 of 1)
1 7 CANH CANL
15 49 41 15 9 8 TACH CANL CANH
16 13 22 SIL CANH CANL
16 15 14 13 12 11 10 9 BAT
27 28 CANH CANL
3 2 9 8 CANL CANH
3 2 CANH CANL
BLK WIRE
BLU WIRE
BRN WIRE
CANL CANH TS
CANL TC TS
CENTER AIR BAG SENSOR (CENTER OF DASH)
COMBINATION METER ASSEMBLY
DIA
DLC 3 (LEFT SIDE OF DASH)
GRN WIRE
GRN/ LT WIRE
GRY WIRE
HOT AT ALL TIMES DRIVER OBD SIDE J/B FUSE (LEFT END OF DASH)
LT BLU WIRE
LT GRN WIRE
OCCUPANT DETECTION ECU (UNDER FRONT PASSENGER SEAT)
PNK CANH CANL WIRE
PNK TC WIRE
PNK WIRE
POWER STEERING ECU (LEFT SIDE OF DASH)
RED WIRE
RED/BLK WIRE
RIGHT END OF DASH)
SIL
SIL CANH SG CG
STEERING SENSOR (STEERING COLUMN)
TAC
TACH
TIRE PRESSURE WARNING ECU (CENTER OF DASH)
TRANSPONDER KEY ECU (CENTER OF DASH)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YAW RATE SENSOR (UNDER DRIVER'S SEAT)
YEL WIRE
Go to component -> Computer data lines circuit -> CANL TC TS
