Toyota Matrix E130 (2002-2008) Charging circuit

ALT FUSE ALT-S FUSE BATTERY BATTERY GROUND BLK WIRE BLK/WHT WIRE BLU WIRE CHARGE IND COMBINATION METER ENGINE ROOM J/B (ON LEFT SIDE OF ENGINE COMPT) FUSE GENERATOR GRN WIRE HOT AT ALL TIMES ENGINE ROOM R/B (INTEGRAL TO ENGINE ROOM J/B) HOT IN ON OR START INSTRUMENT PANEL GAUGE FUSE J/B (BEHIND LEFT SIDE OF DASH) IGNITION SWITCH INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) JUNCTION CONNECTOR 3, 4 (BEHIND RIGHT SIDE OF DASH) LOCK OFF MAIN FUSE MAIN FUSIBLE LINK (14 GA- NCA WIRE ORG/ WIRE RED WIRE RIGHT J/B (BEHIND UPPER RIGHT SIDE OF DASH) STARTING CIRCUIT WHT WIRE YEL WIRE
