Toyota Matrix E130 (2002-2008) w/ power windows w/o power windows Wiring diagram
This page shows the only wiring diagram for the component.w/ power windows w/o power windows, which is found in the car Toyota Matrix E130 (2002-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ power windows w/o power windows (1 of 1)
3 3 RIGHT REAR DOOR LOCK MOTOR (AT REAR OF RIGHT REAR DOOR)
BACK DOOR LOCK MOTOR (AT CENTER OF BACK DOOR)
BH (AT LEFT QUARTERPANEL)
BLK/ WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
CENTER J/B (BEHIND LEFT SIDE OF DASH)
DETECT
DOOR CONTROL RECEIVER (W/ KEYLESS ENTRY)
DOOR FUSE
ENGINE ROOM R/B (INTEGRAL TO ENGINE ROOM J/B)
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES DOME FUSE
IG (BEHIND RIGHT KICK PANEL)
INTEGRATION RELAY
J/C 2 (BEHIND LEFT SIDE OF DASH)
J/C 7 (AT RIGHT KICK PANEL)
J/C 8 (AT LEFT REAR OF VEHICLE)
J/C 8, 9 (AT LEFT REAR OF VEHICLE)
LEFT FRONT DOOR LOCK CONTROL SWITCH
LEFT REAR DOOR LOCK MOTOR
LOCK
LSWD
LSWP
LSWR
RED WIRE
RIGHT FRONT DOOR LOCK CONTROL SWITCH
UNLK
UNLOCK WARNING SWITCH (ON STEERING COLUMN, BEHIND IGNITION KEY CYLINDER)
W/ POWER WINDOWS W/O POWER WINDOWS
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
Go to component -> Power door locks circuit (1 of 2) -> W/ POWER WINDOWS W/O POWER WINDOWS
