Toyota Matrix E130 (2002-2008) stereo component amplifier (under front Wiring diagram
This page shows the only wiring diagram for the component.stereo component amplifier (under front, which is found in the car Toyota Matrix E130 (2002-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram stereo component amplifier (under front (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 -B
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 MUTE L- L+ R- R+
AMP FUSE
ANT
ANTENNA AMPLIFIER (BEHIND RIGHT SIDE OF DASH)
BLK WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
CENTER J/B (BEHIND LEFT SIDE OF DASH)
CIG FUSE
DOME FUSE
ENGINE ROOM R/B (INTEGRAL TO ENGINE ROOM J/B)
GND TWL- TWR- FL- FR-
GRN WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
IF (BEHIND LEFT SIDE OF DASH)
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
J/C 7 (AT RIGHT
KICK PANEL)
LEFT FRONT DOOR SPEAKER
LEFT REAR DOOR SPEAKER RIGHT REAR DOOR SPEAKER
LEFT TWEETER
LT GRN WIRE
MUTE R+ L+ SLD
NCA WIRE
PASSENGER SEAT
PNK TX- WIRE
PNK WIRE
R- L- GND
RADIO, PLAYER
RED WIRE
RED/WHT WIRE
RIGHT FRONT DOOR SPEAKER
RIGHT J/B (BEHIND UPPER RIGHT SIDE OF DASH)
RIGHT TWEETER
RL RR
RL+ RR+ TWL+ TWR+ FL+ FR+
STEREO COMPONENT AMPLIFIER (UNDER FRONT
TX- TX+ PNK WIRE
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WOOFER
YEL WIRE
Go to component -> Radio circuit, without navigation with separate amplifier -> STEREO COMPONENT AMPLIFIER (UNDER FRONT
