Toyota Matrix E130 (2002-2008) radiator fan resistor (at left front Wiring diagram
This page shows the only wiring diagram for the component.radiator fan resistor (at left front, which is found in the car Toyota Matrix E130 (2002-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram radiator fan resistor (at left front (1 of 1)
BLK/RED WIRE
BLK/WHT WIRE
BLU/WHT WIRE
BRN WIRE
DUAL
EA (AT FRONT SIDE OF RIGHT FENDER)
EB (ON LEFT FRONT SUSPENSION TOWER)
ECU-IG FUSE
ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH, BELOW GLOVE BOX)
ENGINE COOLANT TEMPERATURE SENSOR (ON REAR OF ENGINE, ON COOLANT OUTLET)
ENGINE ROOM R/B (INTEGRAL TO ENGINE ROOM J/B)
FAN
FAN 1 RELAY
FAN 2 RELAY
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
JUNCTION CONNECTOR 5, 6 (BEHIND RIGHT SIDE OF DASH)
LT GRN WIRE
LT GRN/BLK WIRE
OF ENGINE COMPT)
PRESSURE SWITCH (AT RIGHT SIDE OF ENGINE COMPT)
RADIATOR FAN MOTOR (BEHIND LEFT SIDE OF RADIATOR)
RADIATOR FAN RESISTOR (AT LEFT FRONT
RDI FAN FUSE
SINGLE
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Cooling fan circuit -> RADIATOR FAN RESISTOR (AT LEFT FRONT
