Toyota Matrix E130 (2002-2008) pnk slt- slt+ Wiring diagrams
This page contains all the electrical diagrams for the component. pnk slt- slt+, in which he is found in the car Toyota Matrix E130 (2002-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram pnk slt- slt+ (1 of 2)
AF-
AIR FUEL RATIO SENSOR (BANK 1 SENSOR 1) (RIGHT REAR OF ENGINE)
ANTI-LOCK BRAKES SYSTEM
BATT MPMP TACH
BLK WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
C/OPN RELAY
CAMSHAFT POSITION SENSOR (LEFT REAR OF ENGINE)
CENTER J/B (BEHIND LEFT SIDE OF DASH)
COOLING FANS SYSTEM
CRANKSHAFT POSITION SENSOR (ON LOWER LEFT FRONT OF ENGINE)
EC (REAR LEFT SIDE OF CYL HEAD)
ED (LEFT REAR SIDE OF ENG)
EFI RELAY
EKNK
ELS
ENG+ VSC+ VCPA ANTI-LOCK BRAKES SYSTEM
ENG- VSC- ANTI-LOCK BRAKES SYSTEM
ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) EFI FUSE
F/PS EOM
FUSE
GRN WIRE
GRN/RED WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ DEF RELAY ENERGIZED
IGNITION SWITCH
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
J/C 3, J/C 4 (RIGHT SIDE OF DASH)
J/C 7 (RIGHT KICK PANEL) J/C 5, J/C 6 (RIGHT SIDE OF DASH)
LOCK
LT GRN WIRE
M- M+
M-HTR/ DEF I-UP FUSE
MREL IGSW FC
NCA WIRE
NE+
NEO SIL WFSE TC PPMP VPA
PNK SLT- SLT+ WIRE
PNK WIRE
PNK/BLK WIRE
PSW
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RUN WIRE
SUPPLEMENTAL RESTRAINTS SYSTEM
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.8l, 2wd except xrs (1 of 4) -> PNK SLT- SLT+ WIRE
Wiring diagram pnk slt- slt+ (2 of 2)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22-31 (NOT USED) +B
BH (AT LEFT QUARTER PANEL)
BLK WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRAID
BRN WIRE
C/OPN RELAY
CENTER J/B (BEHIND LEFT SIDE OF DASH)
CENTER J/B (LEFT SIDE OF DASH)
CRUISE CONTROL ECU (BEHIND LEFT SIDE OF DASH)
CRUISE CONTROL SYSTEM
EC (REAR LEFT SIDE OF CYL HEAD)
ECT
ED MPMP FAN COOLING FANS SYSTEM
EFI RELAY
EKNK
ELS
ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH, BELOW GLOVE BOX)
ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT) EFI FUSE
EVP ST CF COOLING FANS SYSTEM
F/PS EOM
FUEL PUMP
GRN WIRE
GRN/RED WIRE
GRY WIRE
HEATED OXYGEN SENSOR BANK 1, SENSOR 2 (ON EXHAUST PIPE, UNDER CENTER OF VEHICLE)
HEATED OXYGEN SENSOR, BANK 1 SENSOR 1 (ON EXHAUST PIPE, RIGHT REAR OF ENG)
HOT AT ALL TIMES
HOT W/ DEF RELAY ENERGIZED
IE (BEHIND LEFT SIDE OF DASH)
IGNITION SWITCH
IGNSW
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
J/C 2
J/C 3 BEHIND RIGHT SIDE DASH)
J/C 5, J/C 6 (BEHIND RIGHT SIDE OF DASH)
J/C 7 (BEHIND RIGHT KICK PANEL)
LOCK
LT GRN WIRE
LT GRN/BLK WIRE
M-HTR/ DEF I-UP FUSE
NT+ HP EC A/C SYSTEM
NT-
PNK 7 8 9 WIRE
PNK SLT- SLT+ WIRE
PNK WFSE TC PTNK WIRE
PNK WIRE
PNK/BLK WIRE
PSW THO
RED/WHT WIRE
RED/YEL WIRE
RUN WIRE
SUPPLEMENTAL RESTRAINTS SYSTEM
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.8l, 4wd except xrs (1 of 3) -> PNK SLT- SLT+ WIRE
