Toyota Matrix E130 (2002-2008) leak detection pump assembly Wiring diagram
This page shows the only wiring diagram for the component.leak detection pump assembly, which is found in the car Toyota Matrix E130 (2002-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram leak detection pump assembly (1 of 1)
2005-
AIR PUMP PRESSURE SENSOR (AT FRONT OF ENGINE)
BH (LEFT QUARTER- PANEL)
BLK WIRE
BLK/BLU WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRAID
BRN WIRE
CENTER J/B (BEHIND CENTER OF DASH)
COMBINATION METER
EC (REAR OF ENGINE)
EFII
EFIO
EVAP VSV (LEFT REAR OF ENGINE COMPT)
GRN WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
J/C 3, J/C 4 (RIGHT SIDE OF DASH)
J/C 8, J/C 9 (LEFT REAR OF VEHICLE)
KNOCK SENSOR (BANK 1) (LEFT SIDE OF ENG)
LEAK DETECTION PUMP ASSEMBLY
MALFUNCTION INDICATOR LAMP
MASS AIR FLOW METER (LEFT REAR OF ENGINE COMPT)
MGND
MTRB
OIL PRESSURE SWITCH (VVTL) (LOWER LEFT SIDE OF ENGINE)
PIM
PNK 6 7 8 WIRE
PNK WIRE
PNK/BLK WIRE
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT J/B (BEHIND UPPER RIGHT SIDE OF DASH)
SGND
SIL
STOP FUSE
STOPLAMP SWITCH (ON BRAKE PEDAL SUPPORT BRACKET)
THA
TRANSPONDER KEY COMPUTER (LEFT SIDE OF DASH)
VCC
VGND
VIO/WHT WIRE
VLVB
VOUT
WFSE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Wiring diagram engine performance 1.8l, xrs (2 of 3) -> LEAK DETECTION PUMP ASSEMBLY
