Toyota Matrix E130 (2002-2008) fresh air inlet control switch Wiring diagram
This page shows the only wiring diagram for the component.fresh air inlet control switch, which is found in the car Toyota Matrix E130 (2002-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fresh air inlet control switch (1 of 1)
A/C FUSE
A/C SWITCH
A/C SWITCH, AIR INLET CONTROL SWITCH
AIR INLET CONTROL SWITCH
AIR INLET SERVO CONTROL MOTOR (BEHIND GLOVE BOX)
BLK WIRE
BLK/WHT WIRE
BLOWER MOTOR (BELOW RIGHT SIDE OF DASH, IN HEATER-A/C HOUSING)
BLOWER RESISTOR (BELOW RIGHT SIDE OF DASH, IN HEATER-A/C HOUSING)
BLOWER SWITCH
BLU/BLK WIRE
BLU/WHT WIRE
DEFROSTER MODE SWITCH
DOME FUSE
ENGINE ROOM R/B (INTEGRAL TO ENGINE ROOM J/B)
FRESH
FRESH AIR INLET CONTROL SWITCH
GAUGE FUSE
GRN WIRE
GRN/WHT WIRE
HEATER FUSE
HOT AT ALL TIMES
HOT IN ON OR START
HTR RELAY
ILLUM
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
JUNCTION CONNECTOR
JUNCTION CONNECTOR 7 (AT RIGHT KICK PANEL)
OFF LOW
PNK 7 4 WIRE
PNK WIRE
RECIRC
RED WIRE
RED/WHT WIRE
RIGHT J/B (BEHIND UPPER RIGHT SIDE OF DASH)
VIO WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Manual a/c circuit (1 of 2) -> FRESH AIR INLET CONTROL SWITCH
