Toyota Matrix E130 (2002-2008) efi relay fan 2 relay Wiring diagram
This page shows the only wiring diagram for the component.efi relay fan 2 relay, which is found in the car Toyota Matrix E130 (2002-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram efi relay fan 2 relay (1 of 1)
3 4 (XRS) (EXCEPT
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL WARNING SWITCH
BRN WIRE
CAMSHAFT POSITION SENSOR SHIELD CRANKSHAFT POSITION SENSOR SHIELD
COMBINATION SWITCH
DATA LINK CONNECTOR 3
DAYTIME RUNNING LIGHT RELAY RADIATOR FAN RESISTOR
EA (AT FRONT SIDE OF RIGHT FENDER)
EB (LEFT FRONT SUSPENSION TOWER)
EC (XRS: AT REAR OF ENGINE) (EXCEPT XRS: AT REAR LEFT SIDE OF CYLINDER HEAD)
EFI RELAY FAN 2 RELAY
ENGINE CONTROL MODULE
EXCEPT XRS
FRONT WIPER MOTOR
HEATED OXYGEN SENSOR (BANK 1 SENSOR 1) SHIELD
HEATED OXYGEN SENSOR (BANK 1 SENSOR 2) SHIELD
HEATED OXYGEN SENSOR (BANK 1, SENSOR 1) KNOCK SENSOR (BANK 1) SHIELD
HEATED OXYGEN SENSOR BANK 1 SENSOR 2
J/C 3, 4 (BEHIND RIGHT SIDE OF DASH)
J/C 5, 6 (BEHIND RIGHT SIDE OF DASH)
LEFT FRONT PARKING/ TURN SIGNAL LAMP LEFT FRONT FOG LAMP
LEFT HEADLIGHT (HIGH)
LT GRN WIRE
NCA WIRE
OCCUPANT CLASSIFICATION ECU COMBINATION METER
PRESSURE SWITCH
RED WIRE
RIGHT FRONT FOG LAMP
RIGHT FRONT PARKING/ TURN SIGNAL LAMP
RIGHT HEADLIGHT (HIGH)
WASHER LEVEL SENSOR
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (1 of 4) -> EFI RELAY FAN 2 RELAY
