Toyota Matrix E130 (2002-2008) cse cso csb Wiring diagram
This page shows the only wiring diagram for the component.cse cso csb, which is found in the car Toyota Matrix E130 (2002-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cse cso csb (1 of 1)
+B FOG HIND H-LP
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 DRL
1 4 3 CLTB CLTS CLTE
28 23 (W/ VSC) (W/O VSC)
AUTOMATIC LIGHT CONTROL SENSOR
BLK WIRE
BLU/WHT WIRE
BRAKE FLUID LEVEL WARNING SWITCH (ON BRAKE FLUID RESERVOIR)
BRK PKB IG DIM TAIL
CENTER J/B (BEHIND LEFT SIDE OF DASH)
CHG- STARTING/CHARGING SYSTEM
COMBINATION METER
COMBINATION SWITCH
CSE CSO CSB
DAYTIME RUNNING LIGHT RELAY (BEHIND LEFT SIDE OF DASH)
DIMMER RELAY
DIMMER SWITCH
EA (AT FRONT SIDE OF RIGHT FENDER)
EB (LEFT FRONT SUSPENSION TOWER)
ECU-B FUSE
ENGINE ROOM R/B (INTEGRAL TO ENGINE ROOM J/B)
EXTERIOR LIGHTS SYSTEM (USA)
FOG FUSE
FOG RELAY
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HEAD
HEAD IND (USA)
HEAD RELAY
HIGH BEAM IND
HIGH LOW
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) GAUGE FUSE
JUNCTION CONNECTOR 1 (AT LEFT SIDE OF ENGINE COMPT)
JUNCTION CONNECTOR 2 (BEHIND LEFT SIDE OF DASH)
LEFT FRONT FOG LIGHT
LEFT HEADLIGHT (HIGH)
LEFT HEADLIGHT (LOW)
LEFT LWR HEAD FUSE
LEFT UPR HEAD FUSE
LIGHT CONTROL SWITCH
MAIN HEAD FUSE DOME FUSE
OFF
ON FOGLIGHT SWITCH
PARKING BRAKE SWITCH (AT BASE OF PARK BRAKE LEVER)
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT FOG LIGHT
RIGHT HEADLIGHT (HIGH)
RIGHT HEADLIGHT (LOW)
RIGHT J/B (BEHIND UPPER RIGHT SIDE OF DASH)
RIGHT LWR HEAD FUSE
RIGHT UPR HEAD FUSE
SKID CONTROL ECU WITH ACTUATOR (AT RIGHT FRONT SIDE OF ENGINE COMPARTMENT) PKB
TAIL
USA
W/ ABS
W/O ABS
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Headlights circuit -> CSE CSO CSB
