Toyota Matrix E130 (2002-2008) cruise control ecu Wiring diagram
This page shows the only wiring diagram for the component.cruise control ecu, which is found in the car Toyota Matrix E130 (2002-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cruise control ecu (1 of 1)
AIR BAG SENSOR ASSEMBLY
BLK WIRE
BLOWER RESISTOR
BLOWER SWITCH
CENTER J/B (BEHIND LEFT SIDE
COMBINATION METER
COMBINATION SWITCH
CRUISE CONTROL ACTUATOR
CRUISE CONTROL ECU
DATA LINK CONNECTOR 3
ENGINE CONTROL MODULE
IE (BEHIND LEFT SIDE OF DASH)
IG (BEHIND RIGHT KICK PANEL)
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
INTEGRATION RELAY
INTERIOR LIGHT)
J/C 2
J/C 7
LEFT FRONT DOOR LOCK CONTROL SWITCH
LUGGAGE COMPARTMENT LIGHT
MOON ROOF CONTROL RELAY, SWITCH, PERSONAL RELAY
MOON ROOF MOTOR, LIMIT SWITCH
NOISE FILTER
OF DASH)
P/W RELAY ST RELAY
REAR WINDOW DEFOGGER SWITCH
RELAY
REMOTE CONTROL MIRROR SWITCH
RHEOSTAT VOLTAGE INVERTER
RIGHT FRONT DOOR LOCK CONTROL SWITCH
TIRE PRESSURE STANDARDIZATION SWITCH
TO RIGHT J/B (DIAGRAM 4 OF 4)
TURN SIGNAL FLASHER RELAY
UNLOCK WARNING SWITCH
USA
W/ MOON- ROOF
W/ MOONROOF
W/O MOON- ROOF
W/O MOONROOF
W/O POWER WINDOW
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (3 of 4) -> CRUISE CONTROL ECU
