Toyota Matrix E130 (2002-2008) airbag sensor assembly Wiring diagram
This page shows the only wiring diagram for the component.airbag sensor assembly, which is found in the car Toyota Matrix E130 (2002-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram airbag sensor assembly (1 of 1)
AIRBAG SENSOR ASSEMBLY
BLK WIRE
BLU WIRE
BLU/WHT WIRE
CENTER J/B (BEHIND LEFT SIDE OF DASH)
CIG FUSE
CLOCK
COMBINATION METER
DOME FUSE
ENGINE ROOM RELAY BOX (INTEGRAL TO ENGINE ROOM JUNCTION BOX)
GAUGE FUSE
GRY WIRE
HOT AT ALL TIMES
HOT IN
IG (BEHIND RIGHT KICK PANEL)
INSTRUMENT PANEL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
P-AB
PAON
PNK P-AB PAON WIRE
PNK WIRE
RED WIRE
RED/WHT WIRE
RELAY ENERGIZED
RIGHT J/B (BEHIND UPPER RIGHT SIDE OF DASH)
WHT WIRE
WHT/BLK WIRE
Go to component -> Clock circuit -> AIRBAG SENSOR ASSEMBLY
