Toyota Matrix E130 (2002-2008) a/c switch, air inlet control switch Wiring diagrams
This page contains all the electrical diagrams for the component. a/c switch, air inlet control switch, in which he is found in the car Toyota Matrix E130 (2002-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram a/c switch, air inlet control switch (1 of 3)
A/C SWITCH, AIR INLET CONTROL SWITCH
A/T
BLK WIRE
BLOWER SWITCH ILLUMINATION
CLOCK
DEFROSTER MODE SWITCH
FROM J/C 7 (DIAGRAM 3 OF 4)
GLASS BREAKAGE SENSOR ECU
HAZARD SWITCH
HAZARD SWITCH ILLUMINATION
LEFT BUCKLE SWITCH, SEAT POSITION SENSOR
MAIN SWITCH
MAIN SWITCH ILLUMINATION
O/D MAIN SWITCH
P-POINT RELAY INV RELAY
REAR WINDOW DEFOGGER SWITCH ILLUMINATION
RIGHT J/B (BEHIND UPPER RIGHT SIDE OF DASH)
SECURITY INDICATOR
SHIFT LOCK CONTROL ECU AIR INLET CONTROL SWITCH
STEERING SENSOR
TO J/C 2 (DIAGRAM 3 OF 4)
TRAC OFF SWITCH
TRANSPONDER KEY COMPUTER
TVIP ECU
W/ VSC
WHT WIRE
WHT/BLK WIRE
YAW RATE SENSOR
Go to component -> Ground distribution circuit (4 of 4) -> A/C SWITCH, AIR INLET CONTROL SWITCH
Wiring diagram a/c switch, air inlet control switch (2 of 3)
A/C SWITCH, AIR INLET CONTROL SWITCH
A/T SHIFT LEVER ILLUMINATION (A/T)
BLK WIRE
BLOWER SWITCH
BLU WIRE
BRN WIRE
CANADA
CANADA USA
CENTER J/B (BEHIND LEFT SIDE OF DASH)
CIGARETTE LIGHTER ILLUMINATION (IF EQUIPPED)
COMBINATION METER
COMBINATION SWITCH
DAYTIME RUNNING LIGHT RELAY (BEHIND LEFT SIDE OF DASH)
ENGINE DOME FUSE ROOM R/B (INTEGRAL TO ENGINE ROOM J/B)
GAUGE FUSE
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
HAZARD SWITCH
HEAD OFF LIGHT CONTROL SWITCH TAIL
HOT AT ALL TIMES
HOT IN ON OR START
IF (BEHIND LEFT
ILL+ TC
INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH) TAIL FUSE
J/C 2 (BEHIND LEFT SIDE OF DASH)
J/C 7 (BEHIND LEFT KICK PANEL)
MAIN SWITCH (W/ A/C 115 VOLTS POWER OUTLET)
PARK
RADIO, PLAYER (W/O NAVIGATION)
RADIO, PLAYER WITH DISPLAY (W/ NAVIGATION SYSTEM)
REAR WINDOW DEFOGGER SWITCH
RED WIRE
RED/WHT WIRE
RHEOSTAT
RIGHT J/B (BEHIND UPPER RIGHT SIDE OF DASH)
RIGHT R/B (INTEGRAL TO RIGHT J/B)
SIDE OF DASH)
TAIL
TAIL RELAY (USA)
TRAC OFF SWITCH
USA
USA CANADA
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
Go to component -> Instrument illumination circuit -> A/C SWITCH, AIR INLET CONTROL SWITCH
Wiring diagram a/c switch, air inlet control switch (3 of 3)
A/C FUSE
A/C SWITCH
A/C SWITCH, AIR INLET CONTROL SWITCH
AIR INLET CONTROL SWITCH
AIR INLET SERVO CONTROL MOTOR (BEHIND GLOVE BOX)
BLK WIRE
BLK/WHT WIRE
BLOWER MOTOR (BELOW RIGHT SIDE OF DASH, IN HEATER-A/C HOUSING)
BLOWER RESISTOR (BELOW RIGHT SIDE OF DASH, IN HEATER-A/C HOUSING)
BLOWER SWITCH
BLU/BLK WIRE
BLU/WHT WIRE
DEFROSTER MODE SWITCH
DOME FUSE
ENGINE ROOM R/B (INTEGRAL TO ENGINE ROOM J/B)
FRESH
FRESH AIR INLET CONTROL SWITCH
GAUGE FUSE
GRN WIRE
GRN/WHT WIRE
HEATER FUSE
HOT AT ALL TIMES
HOT IN ON OR START
HTR RELAY
ILLUM
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
JUNCTION CONNECTOR
JUNCTION CONNECTOR 7 (AT RIGHT KICK PANEL)
OFF LOW
PNK 7 4 WIRE
PNK WIRE
RECIRC
RED WIRE
RED/WHT WIRE
RIGHT J/B (BEHIND UPPER RIGHT SIDE OF DASH)
VIO WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Manual a/c circuit (1 of 2) -> A/C SWITCH, AIR INLET CONTROL SWITCH
