Toyota Matrix E130 (2002-2008) abs deceleration sensor Wiring diagram

+BM 7 13 12 SIL TC TS ABS 1 FUSE ABS 2 FUSE ABS DECELERATION SENSOR ABS IND. BLK WIRE BLK/ORG WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRAKE FLUID LEVEL WARNING SWITCH (ON BRAKE FLUID RESERVOIR) BRAKE IND BRK PKB BRL RR (-) RR (+) BRN WIRE CENTER J/B (BEHIND LEFT SIDE OF DASH) COMBINATION METER D/G STP RL+ RL- WA DATA LINK CONNECTOR 3 (BELOW LEFT SIDE OF DASH) DAYTIME RUNNING LIGHT RELAY (BEHIND LEFT SIDE OF DASH) DOME FUSE EB (AT LEFT FRONT EC (EXCEPT XRS: AT REAR LEFT SIDE OF CYLINDER HEAD) (XRS: AT REAR OF ENGINE) ECU-IG FUSE ENGINE ROOM J/B ENGINE ROOM R/B (INTEGRAL TO FR- FR+ INIT FUSE (BEHIND LEFT SIDE OF DASH) GAUGE FUSE GGND FL- FL+ GGND VGS GRN WIRE GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START IGNITION SWITCH IND TIRE PRESSURE INSTRUMENT PANEL J/B J/C 3 (BEHIND RIGHT SIDE OF DASH) J/C 5 (BEHIND RIGHT SIDE OF DASH) LEFT FRONT ABS SPEED SENSOR (ON INSIDE OF LEFT FRONT WHEEL ASSEMBLY) LEFT REAR ABS SPEED SENSOR (ON INSIDE OF RIGHT REAR WHEEL ASSEMBLY) LT GRN WIRE ORG/ WIRE PARK/NEUTRAL POSITION SWITCH (ON LEFT SIDE OF TRANSAXLE) PARKING BRAKE SWITCH (AT BASE OF PARK BRAKE LEVER) PNK/BLK WIRE RED WIRE RED/BLK WIRE RED/WHT WIRE RIGHT FRONT ABS SPEED SENSOR (ON INSIDE OF RIGHT FRONT WHEEL ASSEMBLY) RIGHT J/B (BEHIND UPPER RIGHT SIDE OF DASH) SPEEDOMETER STOP FUSE STOP LIGHT SWITCH SUSPENSION TOWER) TIRE PRESSURE WARNING STANDARDIZATION SWITCH TS TC VGS VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE WTIR TSI YEL WIRE YEL/BLK WIRE YEL/RED WIRE
