Toyota Matrix E130 (2002-2008) 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 bat wfse canl tc ts pnk Wiring diagram
This page shows the only wiring diagram for the component.16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 bat wfse canl tc ts pnk, which is found in the car Toyota Matrix E130 (2002-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 bat wfse canl tc ts pnk (1 of 1)
16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 BAT WFSE CANL TC TS PNK WIRE
AIR BAG SENSOR ASSEMBLY (BELOW CENTER OF DASH)
BLK WIRE
BLK/YEL WIRE
BLU/RED WIRE
BRN WIRE
CENTER J/B (BEHIND LEFT SIDE OF DASH)
COMBINATION METER
CRUISE CONTROL ECU (BEHIND LEFT SIDE OF DASH)
D/G
DATA LINK CONNECTOR 3 (BELOW LEFT SIDE OF DASH)
DIA
EC (EXCEPT XRS: AT REAR LEFT SIDE OF CYLINDER HEAD) (XRS: AT REAR OF ENGINE)
ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH, BELOW GLOVE BOX) XRS
EXCEPT XRS
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
J/C 13 (BEHIND LEFT SIDE OF DASH)
J/C 2 (BEHIND LEFT SIDE OF DASH) IE
J/C 3, 4 (BEHIND RIGHT SIDE OF DASH)
OBD FUSE
OCCUPANT CLASSIFICATION ECU (UNDER FRONT PASSENGER SEAT)
PNK WIRE
PNK/BLK WIRE
RED/BLK WIRE
RIGHT J/B (BEHIND UPPER RIGHT SIDE OF DASH)
SIL
SIL CANH SG CG
SKID CONTROL ECU WITH ACTUATOR
STEERING SENSOR
WFSE
WHT WIRE
WHT/BLK WIRE
YAW RATE SENSOR (UNDER LEFT FRONT SEAT)
Go to component -> Computer data lines circuit -> 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 BAT WFSE CANL TC TS PNK WIRE
