Toyota Matrix E130 (2002-2008) 1 2 3 4 7 6 5 8 9 10 11 12 13 14 +b ig ind cty efii efio agnd vcs Wiring diagram

1 2 3 4 7 6 5 8 9 10 11 12 13 14 +B IG IND CTY EFII EFIO AGND VCS 1.8L XRS 1.8L EXCEPT XRS 1.8L EXCEPT XRS 2WD 1.8L XRS, 1.8L EXCEPT 2 3 4 26 27 IMO IMI 5 4 1 7 TXCT CODE VCS GND 9 3 1 15 18 8 IGSW BATT +B EOM SIL MREL BLK WIRE BLK/ORG WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE CENTER J/B (BEHIND LEFT SIDE OF DASH) EB (ON LEFT FRONT SUSPENSION TOWER) ECU-B FUSE EFI FUSE ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH, BELOW GLOVE BOX) ENGINE EFI 2 FUSE ROOM R/B (INTEGRAL TO ENGINE ROOM J/B) ENGINE ROOM R/B (INTEGRAL TO ENGINE ROOM J/B) EFI RELAY EXCEPT EXCEPT GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START IGNITION SWITCH INSTRUMENT PANEL J/B INSTRUMENT PANEL J/B (BEHIND LEFT INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) J/C 2 (AT LEFT REAR OF VEHICLE) J/C 7 (AT RIGHT KICK PANEL) KSW CODE TXCT LEFT FRONT DOOR COURTESY SWITCH LOCK ON OFF RED WIRE RED/BLK WIRE RED/WHT WIRE RH J/B (INTEGRAL TO RH J/B) RIGHT SIDE J/B (BEHIND UPPER RIGHT SIDE OF DASH) SECURITY INDICATOR SIDE OF DASH) TRANSPONDER KEY AMPLIFIER (RIGHT SIDE OF STEERING WHEEL) TRANSPONDER KEY COMPUTER (BEHIND LEFT SIDE OF DASH) UNLOCK WARNING SWITCH (ON STEERING COLUMN, BEHIND IGNITION KEY CYLINDER) WHT WIRE WHT/BLK WIRE XRS, EXCEPT XRS, EXCEPT YEL WIRE
