Car Wiring Diagrams for Dynamic laser cruise control circuit for Toyota Land Cruiser 200 facelift 2 (2015-2021)

ACCELERATOR PEDAL SENSOR ASSEMBLY BLK WIRE BLU WIRE BRN WIRE CAN (-) CAN (+) CANN CANP COMPUTER DATA LINES SYSTEM CRUISE CONTROL MAIN SWITCH CRUISE CONTROL SWITCH DISTANCE CONTROL ECCS EFI MAIN RELAY 1 EFI- MAIN 1 FUSE ENGINE CONTROL MODULE ENGINE ROOM J/B ASSEMBLY ENGINE ROOM R/B ASSEMBLY GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ACC RELAY ENERGIZED INSTRUMENT CLUSTER SYSTEM LEFT COWL SIDE J/B ASSEMBLY MAIN NCA WIRE ORG/ WIRE PARK/NEUTRAL POSITION SWITCH (RIGHT SIDE OF TRANSMISSION) PNK WIRE RED WIRE RELAY ENERGIZED RIGHT END OF DASH) RIGHT STEERING PAD SWITCH SPIRAL CABLE SUB-ASSEMBLY STEERING PAD SWITCH ASSEMBLY STOP FUSE STOP LIGHT SWITCH ASSEMBLY THROTTLE BODY ASSEMBLY (TOP RIGHT FRONT OF ENGINE) TRANSMISSION CONTROL ECU ASSEMBLY VIO WIRE WHT WIRE WHT/BLK WIRE

BLK WIRE BLU WIRE BRN WIRE BUZZER CAN INPUT COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM CRUISE IND ECU- IG 6 FUSE ECU-IG 2 FUSE GRN WIRE HOT W/ IG 4 RELAY ENERGIZED IGB LEFT COWL SIDE J/B ASSEMBLY LEFT FRONT SPEED SENSOR LEFT REAR SPEED SENSOR LF+ LR (-) LT GRN WIRE MAIN RELAY ENERGIZED METER FUSE MILLIMETER WAVE RADAR SENSOR ASSEMBLY NCA WIRE ONE STEP DIM ORG/ WIRE PBSW PNK WIRE POWER SUPPLY CIRCUIT RADAR CRUISE IND RED WIRE RELAY ENERGIZED RF+ RIGHT COWL SIDE J/B ASSEMBLY RIGHT END OF DASH) RIGHT FRONT SPEED SENSOR RIGHT REAR SPEED SENSOR SET IND SGND SKID CONTROL ECU W/ ACTUATOR SPSW SUB + SUPPLEMENTAL RESTRAINTS SYSTEM TFT VIO WIRE WHT WIRE WHT/BLK WIRE
