Instrument illumination circuit for Toyota Highlander III facelift (2016-2019)

2.7L, 3.5L HYBRID 3.5L A/C CONTROL ASSEMBLY A/C CONTROL ASSEMBLY 2 ACAN AUTO BLK WIRE BRN WIRE CERTIFICATION ECU (W/ SMART KEY SYSTEM) (RIGHT END OF DASH) COMPUTER DATA LINES SYSTEM CRUISE CONTROL MAIN SWITCH DC/DC ALT FUSE DCM (TELEMATICS TRANSCEIVER) DOOR CONTROL SWITCH ASSEMBLY ECU-ACC FUSE ENGINE ROOM J/B 1 ASSEMBLY ENGINE SWITCH (EXCEPT HYBRID) EXCEPT HYBRID GLOVE BOX LIGHT ASSEMBLY GRN WIRE GRN/WHT WIRE HEAD HEADLIGHT DIMMER SWITCH ASSEMBLY HOT AT ALL TIMES HOT W/ ACC RELAY ENERGIZED IL+2 IL-2 INSTRUMENT PANEL J/B ASSEMBLY J/B ALT FUSE LEFT STEERING SWITCH LIGHT CONTROL SWITCH LT GRN WIRE MAIN BODY ECU NAVIGATION RECEIVER ASSEMBLY OFF (CANADA) ORG/ WIRE PANEL FUSE PNK WIRE POWER SWITCH (HYBRID) PPL RADIO, DISPLAY RECEIVER ASSEMBLY RED WIRE RELAY 3 ENERGIZED RIGHT STEERING SWITCH SPIRAL CABLE W/ SENSOR SUB-ASSEMBLY STEERING PAD SWITCH ASSEMBLY SWIL SWIL PNK WIRE TAIL TAIL RELAY TO J/C 5 (DIAGRAM 2 OF 3) W/ NAVIGATION SYSTEM W/ SAFETY CONNECT W/O NAVIGATION SYSTEM WHT WIRE WHT/BLK WIRE

BLK WIRE DIFFERENTIAL LOCK SWITCH DOWNHILL ASSIST CONTROL SWITCH EXCEPT HYBRID EXCEPT HYBRID HYBRID FROM J/C 5 (DIAGRAM 1 OF 3) FROM J/C 5 (DIAGRAM 2 OF 3) HEATER SWITCH ASSEMBLY HYBRID EXCEPT HYBRID ILL LEFT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY LEFT SEAT HEATER SWITCH LEFT SEAT MEMORY SWITCH LILL LT BLU WIRE LT GRN WIRE MAP LIGHT ASSEMBLY ORG/ WIRE OUTER MIRROR SWITCH ASSEMBLY PATTERN SELECT SWITCH ASSEMBLY RED WIRE RIGHT FRONT POWER WINDOW REGULATOR SWITCH ASSEMBLY RIGHT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY RIGHT SEAT HEATER SWITCH SEAT HEATER SWITCH SHIFT POSITION INDICATOR TO J/C 5 (DIAGRAM 2 OF 3) VSC OFF SWITCH W/ REAR POWER WINDOW JAM PROTECTION W/ SEAT HEATER, W/O CLIMATE CONTROL SEAT W/O PANORAMIC VIEW MONITOR SYSTEM W/O REAR POWER WINDOW JAM PROTECTION WHT WIRE YEL WIRE

AUTO HIGH BEAM SWITCH BACK SONAR OR CLEARANCE SONAR SWITCH ASSEMBLY BRN WIRE CAN I/F CLOCK ASSEMBLY COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM DOOR CONTROL SWITCH ASSEMBLY ECO RUN CANCEL SWITCH ASSEMBLY ENGINE ROOM R/B 1 ASSEMBLY ENGINE STOP, START ECU FUEL LID OPENER SWITCH GRN WIRE HOT AT ALL TIMES INSTRUMENT PANEL J/B ASSEMBLY LED DRIVER LT BLU WIRE LT GRN WIRE METER FUSE OPTION CONNECTOR (CIGARETTE LIGHTER ILLUMINATION) ORG/ WIRE OUTER MIRROR HEATER SWITCH ASSEMBLY POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY RED WIRE RELAY ENERGIZED STEERING HEATER SWITCH TELLTALES W/ REAR POWER WINDOW JAM PROTECTION W/ STOP/ START SYSTEM W/O REAR POWER WINDOW JAM PROTECTION W/O STOP/ START SYSTEM WHT WIRE
