Toyota Highlander III facelift (2016-2019) door control receiver sub-assembly Wiring diagrams

This page contains all the electrical diagrams for the component. door control receiver sub-assembly, in which he is found in the car Toyota Highlander III facelift (2016-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

door control receiver sub-assembly wiring diagram (1 of 4)

BACK WINDOW LOCK ASSEMBLY BEHIND LEFT QUARTERPANEL) BLK WIRE BLU WIRE BRN WIRE DOOR CONTROL RECEIVER SUB-ASSEMBLY DOOR CONTROL SWITCH DOOR CONTROL SWITCH ASSEMBLY GRY WIRE LEFT POWER BACK DOOR SENSOR ASSEMBLY LT BLU WIRE LT GRN WIRE ORG/ WIRE PNK WIRE RED WIRE RIGHT POWER BACK DOOR SENSOR ASSEMBLY UN-LOCK WARNING SWITCH ASSEMBLY W/ GLASS HATCH OPENER WHT WIRE WHT/BLK WIRE WIRELESS DOOR LOCK BUZZER YEL WIRE

Go to component -> Back door opener circuit, w/ power back door (2 of 3) -> DOOR CONTROL RECEIVER SUB-ASSEMBLY

door control receiver sub-assembly wiring diagram (2 of 4)

BACK WINDOW LOCK ASSEMBLY BEHIND LEFT QUARTERPANEL) BLK WIRE BLU WIRE BRN WIRE CAN (+) CAN I/F COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM COURTESY DISPLAY DRIVER DOOR CONTROL RECEIVER SUB-ASSEMBLY DRIVER LED ECM 3.5L GBSI GRN WIRE GRY WIRE LT BLU WIRE LT GRN WIRE OPTION CONNECTOR (REMOTE ENGINE STARTER, GLASS BREAKAGE SENSOR) ORG/ WIRE PNK WIRE RED WIRE RIGHT END OF DASH) SPEAKER TELLTALES UNLOCK WARNING SWITCH ASSEMBLY W/ GLASS HATCH OPENER W/ TIRE PRESSURE WARNING SYSTEM W/O STOP, START SYSTEM W/ STOP, START SYSTEM W/O TIRE PRESSURE WARNING SYSTEM WHT WIRE WHT/BLK WIRE

Go to component -> Forced entry circuit, except hybrid w/o smart key system (4 of 4) -> DOOR CONTROL RECEIVER SUB-ASSEMBLY
