Wiring Diagrams for Toyota Highlander III facelift (2016-2019)

A/c circuit, except hybrid Automatic a/c circuit, hybrid

Anti-lock brakes circuit, except hybrid Anti-lock brakes circuit, hybrid

Forced entry circuit, except hybrid w/o smart key system Forced entry circuit, except hybrid w/ smart key system Forced entry circuit, hybrid Immobilizer circuit

Body ecu circuit, except hybrid Body ecu circuit, hybrid Semiconductor power integration ecu circuit, except hybrid Semiconductor power integration ecu circuit, hybrid

Computer data lines circuit, except hybrid Computer data lines circuit, hybrid

Battery cooling fan circuit, hybrid Cooling fan circuit, except hybrid Cooling fan circuit, hybrid

Cruise control circuit, except hybrid Cruise control circuit, hybrid Dynamic laser cruise control circuit, except hybrid Dynamic laser cruise control circuit, hybrid

Front deicer circuit Mirror heater & rear defogger circuit

Electronic power steering circuit

Wiring diagram engine performance 2.7l

Wiring diagram engine performance 3.5l

Wiring diagram engine performance 3.5l hybrid, engine controls circuit Wiring diagram engine performance 3.5l hybrid, hybrid system circuit

Backup lamps circuit, except hybrid Backup lamps circuit, hybrid Exterior lamps circuit Trailer tow circuit

Ground distribution circuit, except hybrid Ground distribution circuit, hybrid

Headlights circuit

Horn circuit

Instrument cluster circuit, except hybrid Instrument cluster circuit, hybrid

Courtesy lamps circuit Instrument illumination circuit

Memory mirrors circuit Memory seat circuit

Blind spot monitoring circuit Lane departure warning circuit Navigation circuit, 12 speakers Navigation circuit, 6 speakers Parking assistant circuit, w/o panoramic Parking assistant circuit, w/ panoramic Telematics circuit Vehicle proximity notification circuit

Power distribution circuit, except hybrid Power distribution circuit, hybrid

Power door locks circuit, except hybrid w/o smart key system Power door locks circuit, except hybrid w/ smart key system Power door locks circuit, hybrid

Electrochromic mirror circuit Power mirrors circuit

Driver power seat circuit Front heated seats circuit, w/ climate control seat Front heated seats circuit, w/o climate control seat Heated steering wheel circuit Passenger power seat circuit Rear heated seats circuit

Panoramic roof circuit Sunroof circuit

Power windows circuit, w/o rear power window jam protection Power windows circuit, w/ rear power window jam protection

12-speaker system circuit 6-speaker system circuit, w/ navigation 6-speaker system circuit, w/o navigation

Shift interlock circuit, except hybrid w/o smart key system Shift interlock circuit, except hybrid w/ smart key system Shift interlock circuit, hybrid Steering column circuit

2.7l, charging circuit 2.7l, starting circuit, w/o smart key system 2.7l, starting circuit, w/ smart key system 2.7l, stop & start circuit

3.5l, charging circuit 3.5l, starting circuit, w/o smart key system 3.5l, starting circuit, w/ smart key system 3.5l, stop & start circuit

Supplemental restraints circuit

2.7l, 4wd circuit 2.7l, a/t circuit

3.5l, 4wd circuit 3.5l, a/t circuit

3.5l hybrid, a/t circuit

Back door opener circuit, w/o power back door Back door opener circuit, w/ power back door Fuel door release circuit, except hybrid Fuel door release circuit, hybrid

Key reminder & seat belt warning circuit Tire pressure monitoring circuit

Front wiper/washer circuit, w/ auto wiper system Front wiper/washer circuit, w/o auto wiper system Rear wiper/washer circuit

A/C AMPLIFIER ASSEMBLY ANTI-LOCK BRAKES SYSTEM ANTI-LOCK BRAKES, ELECTRONIC POWER STEERING SYSTEMS ANTI-LOCK BRAKES, INSTRUMENT CLUSTER SYSTEMS BACK DOOR LOCK ASSEMBLY BACK WINDOW LOCK ASSEMBLY CENTER BATTERY COOLING BLOWER ASSEMBLY CRUISE CONTROL, ANTI-LOCK BRAKES, EXTERIOR LIGHTS SYSTEMS ELECTRONIC POWER STEERING ANTI-LOCK BRAKES SYSTEM GENERATOR ASSEMBLY HIGH PITCHED HORN ASSEMBLY HV SUPPLY BATTERY ASSEMBLY HYBRID BATTERY JUNCTION BLOCK ASSEMBLY HYBRID VEHICLE BATTERY IGNITION COIL ASSEMBLY 1 IGNITION COIL ASSEMBLY 2 IGNITION COIL ASSEMBLY 3 IGNITION COIL ASSEMBLY 4 IGNITION COIL ASSEMBLY 5 IGNITION COIL ASSEMBLY 6 KEY LOCK LEFT BATTERY COOLING BLOWER ASSEMBLY LOCK OFF LOW PITCHED HORN ASSEMBLY NAVIGATION, ANTI-LOCK BRAKES, CRUISE CONTROL SYSTEMS RIGHT BATTERY COOLING BLOWER ASSEMBLY SECURITY HORN ASSEMBLY STARTER ASSEMBLY STEREO COMPONENT AMPLIFIER ASSEMBLY TRANSPONDER KEY COIL W/O SECURITY HORN WIRELESS DOOR LOCK BUZZER

(RIGHT FRONT OF ENGINE (RIGHT SIDE OF ENGINE BLOWER MOTOR CONTROL BLOWER MOTOR W/ FAN SUB-ASSEMBLY BRAKE ACTUATOR ASSEMBLY COMPRESSOR W/ MOTOR ASSEMBLY COOLING FAN MOTOR COOLING FAN MOTOR 2 CRUISE CONTROL, ENGINE CONTROLS, TRANSMISSIONS SYSTEMS ENGINE CONTROLS SYSTEM ENGINE CONTROLS, COOLING FANS SYSTEMS ENGINE CONTROLS, INSTRUMENT CLUSTER, TRANSMISSIONS SYSTEMS ENGINE ROOM J/B 1 ASSEMBLY ENGINE ROOM R/B 1 ASSEMBLY ENGINE ROOM R/B 2 ASSEMBLY ENGINE ROOM R/B 3 ENGINE STOP, START SOLENOID FILTER FUEL LID LOCK W/ MOTOR ASSEMBLY INTAKE AIR CONTROL VALVE ACTUATOR INVERTER WATER PUMP W/ MOTOR ASSEMBLY LEFT FRONT DOOR LOCK W/ MOTOR ASSEMBLY LEFT REAR DOOR LOCK W/ MOTOR ASSEMBLY LOWER RIGHT FRONT OF ENGINE) OIL PUMP W/ MOTOR ASSEMBLY POWER STEERING MOTOR REAR BLOWER MOTOR W/ FAN SUB-ASSEMBLY REAR TRACTION MOTOR W/ TRANSAXLE ASSEMBLY REAR WIPER MOTOR ASSEMBLY RIGHT FRONT DOOR LOCK W/ MOTOR ASSEMBLY RIGHT REAR DOOR LOCK W/ MOTOR ASSEMBLY STEERING LOCK ACTUATOR ASSEMBLY THROTTLE BODY W/ MOTOR ASSEMBLY TOP OF ENGINE) TRANSMISSIONS, ENGINE CONTROLS SYSTEMS WASHER MOTOR, PUMP ASSEMBLY WINDSHIELD WIPER MOTOR ASSEMBLY

GPS ANTENNA GPS, TELEPHONE ANTENNA INDOOR ELECTRICAL KEY ANTENNA ASSEMBLY 1 INDOOR ELECTRICAL KEY ANTENNA ASSEMBLY 2 INDOOR ELECTRICAL KEY ANTENNA ASSEMBLY 3 LEFT FRONT ELECTRICAL KEY ANTENNA RADIO ANTENNA REAR ELECTRICAL KEY ANTENNA RIGHT FRONT ELECTRICAL KEY ANTENNA SDARS ANTENNA TELEPHONE ANTENNA ASSEMBLY

LEFT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY LEFT REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY LEFT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY RIGHT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY RIGHT FRONT POWER WINDOW REGULATOR SWITCH ASSEMBLY RIGHT REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY RIGHT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY

FORWARD RECOGNITION CAMERA FRONT TELEVISION CAMERA ASSEMBLY LEFT SIDE TELEVISION CAMERA ASSEMBLY REAR TELEVISION CAMERA ASSEMBLY RIGHT SIDE TELEVISION CAMERA ASSEMBLY TELEVISION CAMERA ASSEMBLY

CENTER POWER OUTLET SOCKET ASSEMBLY DATA LINK CONNECTOR 3 POWER OUTLET SOCKET ASSEMBLY 1 REAR POWER OUTLET SOCKET ASSEMBLY 2 USB CHARGER SOCKET 1 USB CHARGER SOCKET 2

CERTIFICATION ECU CLEARANCE WARNING ECU ASSEMBLY CONTROL UNIT) COOLING FAN ECU COOLING FAN ECU 2 DRIVING SUPPORT ECU ASSEMBLY ECU-ACC FUSE ECU-IG FUSE ENGINE STOP, START ECU FUEL PUMP CONTROL ECU ASSEMBLY HYBRID VEHICLE CONTROL ECU HYBRID VEHICLE CONTROL ECU ASSEMBLY LEFT OUTER MIRROR CONTROL ECU ASSEMBLY LEFT POWER BACK DOOR UNIT ASSEMBLY SET MAIN BODY ECU MAIN BODY ECU INSTRUMENT PANEL J/B ASSEMBLY MULTIPLEX NETWORK DOOR ECU NETWORK GATEWAY ECU OCCUPANT DETECTION ECU PARKING ASSIST ECU POSITION CONTROL ECU, SWITCH ASSEMBLY POWER STEERING ECU ASSEMBLY RIGHT OUTER MIRROR CONTROL ECU ASSEMBLY RIGHT POWER BACK DOOR UNIT ASSEMBLY SET SEMICONDUCTOR POWER INTEGRATION ECU SEMICONDUCTOR POWER INTEGRATION ECU CIRCUIT SEMICONDUCTOR POWER INTEGRATION ECU CIRCUIT HORNS SYSTEM SEMICONDUCTOR POWER INTEGRATION ECU ENGINE ROOM J/B 1 ASSEMBLY SEMICONDUCTOR POWER INTEGRATION ECU RDEF SHIFT LOCK CONTROL ECU SKID CONTROL ECU ASSEMBLY TRANSPONDER KEY ECU TRANSPONDER KEY ECU ASSEMBLY

A/BAG-IG FUSE A/C FUSE A/C RR FUSE A/C W/ PMP FUSE A/C W/PMP FUSE A/F HTR 2 FUSE A/F HTR FUSE ABS 1 FUSE ABS 2 FUSE ABS MAIN 2 FUSE ABS MAIN 3 FUSE ABS MTR 1 FUSE ABS MTR 2 FUSE ABS- MAIN 1 FUSE ALT FUSE ALT-S FUSE AMP 1 FUSE AMP 2 FUSE BATT FAN FUSE BBC 2 FUSE BBC 3 FUSE BBC FUSE BKUP LP FUSE CAPACITOR FUSE D/L FUSE DC/ DC-S FUSE DC/DC ALT FUSE DC/DC FUSE DC/DC-S FUSE DOME FUSE DOOR BACK FUSE DSS-IG FUSE EDU FUSE EFI 1 FUSE EFI 2 FUSE EFI 3 FUSE EFI 4 FUSE EFI MAIN FUSE EFI- MAIN 2 FUSE EPS FUSE EPS-IG FUSE ETCS FUSE FAN 1 FUSE FAN FUSE FAN-2 FUSE FUEL OPN FUSE FUEL PMP FUSE HAZ FUSE HORN FUSE HP-LP LO LH FUSE HTR FUSE IDLE UP FUSE IGCT 2 FUSE IGCT 3 FUSE INJ FUSE INV FUSE INV W/ PMP FUSE J/B ALT FUSE J/B-ALT ALT FUSE J/B-B FUSE MAIN FUSE MAYDAY FUSE METER FUSE MIR HTR FUSE MPX-B 1 FUSE MPX-B 3 FUSE MPX-B FUSE OBD FUSE ODS FUSE OIL PMP FUSE P/OUTLET 1 FUSE P/OUTLET 2 FUSE P/SEAT F/L FUSE PANEL FUSE PBD FUSE PCU FUSE PM IGCT FUSE PTC HTR 1 FUSE PTC HTR 2 FUSE PTC HTR 3 FUSE R/B 2 FUSE R/B 3 FUSE RADIO FUSE RR A/C FUSE S ROOF FUSE S-HORN FUSE S/HTR F/L FUSE S/HTR F/R FUSE S/HTR RR FUSE S/ROOF FUSE SFT LOCK- ACC FUSE SHADE FUSE ST 2 FUSE ST FUSE STOP FUSE STRG HTR FUSE STRG LOCK FUSE TAIL FUSE TOWING FUSE WASHER FUSE WIPER FR FUSE WIPER RR FUSE

HEADLIGHT DRL/ PARKING LIGHT LEFT HEADLIGHT ASSEMBLY RIGHT HEADLIGHT ASSEMBLY

FORWARD RECOGNITION W/ HEATER HOOD SUB-ASSEMBLY LEFT SEAT HEATER CONTROL SUB-ASSEMBLY MIRROR HEATER QUICK HEATER ASSEMBLY RIGHT SEAT HEATER CONTROL SUB-ASSEMBLY SEAT BACK HEATER SEAT CUSHION HEATER SEAT HEATER CONTROL STEERING WHEEL HEATER STEERING WHEEL HEATER CONTROL ASSEMBLY W/ HEATED STEERING WHEEL SYSTEM W/ SEAT HEATER W/ HEATED STEERING WHEEL SYSTEM W/ SEAT HEATER W/ SMART KEY SYSTEM W/ HEATED STEERING WHEEL SYSTEM, SEAT HEATER W/ SEAT HEATER W/ SEAT HEATER, W/O CLIMATE CONTROL SEAT W/O MEMORY, W/ SEAT HEATER, W/O CLIMATE CONTROL SEAT W/O SEAT HEATER

BLIND SPOT MONITOR INDICATOR SECURITY INDICATOR SHIFT POSITION INDICATOR

ANTI THEFT, INTERIOR LIGHTS, DOOR LOCKS SYSTEMS ANTI-THEFT, DOOR LOCKS, WARNING, INTERIOR LIGHTS SYSTEMS CRUISE CONTROL, TRANSMISSIONS, EXTERIOR LIGHTS, SHIFT INTERLOCK SYSTEMS DEFOGGER, NAVIGATION, EXTERIOR LIGHTS SYSTEMS DOOR LOCKS, ANTI-THEFT, INTERIOR LIGHTS, TRUNK, TAILGATE, FUEL DOORS SYSTEMS EXTERIOR LIGHTS, INTERIOR LIGHTS SYSTEMS HEADLIGHTS SYSTEM ANTI THEFT, DOOR LOCKS, INTERIOR LIGHTS SYSTEMS INSTRUMENT CLUSTER, EXTERIOR LIGHTS SYSTEMS INTERIOR LIGHTS SYSTEM ANTI THEFT, DOOR LOCKS SYSTEMS INTERIOR LIGHTS SYSTEMS ANTI-THEFT, DOOR LOCKS SYSTEMS TRUNK, TAILGATE, FUEL DOORS, ANTI THEFT, INTERIOR LIGHTS, DOOR LOCKS SYSTEMS WARNING SYSTEM ANTI-THEFT, DOOR LOCKS, INTERIOR LIGHTS SYSTEMS

CANISTER PUMP MODULE FUEL PUMP ASSEMBLY FUEL PUMP ASSEMBLY SHIELD FUEL SUCTION TUBE W/ PUMP, GAUGE ASSEMBLY HEATER WATER PUMP ASSEMBLY LEAK DETECTION PUMP

3 RELAY ENERGIZED A/C W/ PMP RELAY A/C W/PMP RELAY A/F RELAY ABS MTR 1 RELAY ABS MTR 2 RELAY AC INVERTER RELAY ACC RELAY ALL DR LOCK RELAY BACK-UP LP RELAY BACKUP LP RELAY BATT FAN RELAY C/OPN RELAY D DR UNLOCK RELAY D INJ RELAY D INJ RELAY SHIELD D/DR UNLOCK RELAY DINJ RELAY DOME CUT RELAY DOOR BACK RELAY EFI MAIN RELAY EFI MAIN RELAY 2 FAN 1 RELAY FAN 2 RELAY FAN RELAY 1 FAN RELAY 2 FUEL LOCK RELAY FUEL OPN RELAY FUEL PMP RELAY GLASS HATCH RELAY 1 H-LP LH-LO RELAY H-LP RH-LO RELAY HORN RELAY HOT W/ ACC RELAY ENERGIZED HOT W/ EFI MAIN RELAY ENERGIZED HOT W/ IGCT RELAY ENERGIZED HOT W/ TAIL RELAY ENERGIZED IGCT RELAY L/D-DR UNLOCK RELAY MAIN RELAY MIR HTR RELAY OIL PMP RELAY OIL PUMP RELAY P/OUTLET RELAY P/OUTLET RELAY 1 P/OUTLET RELAY 2 POWER RELAY PRECHARGE RELAY PTC HTR RELAY 1 PTC HTR RELAY 2 PTC HTR RELAY 3 PWR RELAY RELAY 3 ENERGIZED RELAY ENERGIZED S-HORN RELAY ST 2 RELAY ST RELAY TAIL RELAY WINDSHIELD WIPER RELAY WINDSHIELD WIPER RELAY ASSEMBLY

6 SENSOR A/C PRESSURE SENSOR ACCELERATOR PEDAL SENSOR ASSEMBLY AIR BAG SENSOR ASSEMBLY AUTOMATIC LIGHT CONTROL SENSOR BATTERY CURRENT SENSOR ASSEMBLY BATTERY VOLTAGE SENSOR BRAKE PEDAL STROKE SENSOR ASSEMBLY CANISTER PRESSURE SENSOR CRANK POSITION SENSOR CRANK POSITION SENSOR SHIELD CURRENT SENSOR E.F.I. ENGINE COOLANT TEMPERATURE SENSOR EFI VACUUM SENSOR ASSEMBLY ENGINE OIL LEVEL SENSOR FUEL TANK PRESSURE SENSOR LEFT BLIND SPOT MONITOR SENSOR LEFT DOOR SIDE AIR BAG SENSOR LEFT FRONT AIR BAG SENSOR LEFT FRONT OCCUPANT CLASSIFICATION SENSOR LEFT FRONT SPEED SENSOR LEFT POWER BACK DOOR SENSOR ASSEMBLY LEFT REAR AIR BAG SENSOR LEFT REAR CENTER ULTRASONIC SENSOR 1 LEFT REAR OCCUPANT CLASSIFICATION SENSOR LEFT REAR SPEED SENSOR LEFT REAR ULTRASONIC SENSOR 1 MILLIMETER WAVE RADAR SENSOR ASSEMBLY RAIN SENSOR RIGHT BLIND SPOT MONITOR SENSOR RIGHT DOOR SIDE AIR BAG SENSOR RIGHT FRONT AIR BAG SENSOR RIGHT FRONT SPEED SENSOR RIGHT FRONT ULTRASONIC SENSOR CORNER RIGHT POWER BACK DOOR SENSOR ASSEMBLY RIGHT REAR AIR BAG SENSOR RIGHT REAR CENTER ULTRASONIC SENSOR 1 RIGHT REAR SPEED SENSOR RIGHT REAR ULTRASONIC SENSOR 1 SEAT POSITION AIR BAG SENSOR SHIFT LEVER POSITION SENSOR SOLAR SENSOR SPIRAL CABLE SUB-ASSEMBLY W/ SENSOR SPIRAL CABLE W/ SENSOR SUB-ASSEMBLY STEERING SENSOR TORQUE SENSOR YAW RATE SENSOR YAW RATE SENSOR ASSEMBLY

6 SPEAKER FRONT SPEAKER ASSEMBLY 3 LEFT FRONT SPEAKER ASSEMBLY 1 LEFT FRONT SPEAKER ASSEMBLY 2 LEFT REAR SPEAKER ASSEMBLY LEFT REAR SPEAKER ASSEMBLY 3 REAR SPEAKER ASSEMBLY 2 RIGHT FRONT SPEAKER ASSEMBLY 1 RIGHT FRONT SPEAKER ASSEMBLY 2 RIGHT REAR SPEAKER ASSEMBLY RIGHT REAR SPEAKER ASSEMBLY 3 VEHICLE APPROACHING SPEAKER ASSEMBLY VEHICLE APPROACHING SPEAKER CONTROLLER W/ SEAT HEATER, HEATED STEERING WHEEL SYSTEM 12 SPEAKER W/ STOP, START SYSTEM

AUTO HIGH BEAM SWITCH AUTO WIPER SENSITIVITY ADJUSTMENT SWITCH BACK DOOR CONTROL SWITCH BACK DOOR OPENER SWITCH ASSEMBLY BACK SONAR OR CLEARANCE SONAR SWITCH ASSEMBLY BUCKLE SWITCH BUCKLE SWITCH RIGHT FRONT SEAT INNER BELT ASSEMBLY COURTESY SWITCH CRUISE CONTROL MAIN SWITCH DIFFERENTIAL LOCK SWITCH DIMMER SWITCH DOOR CONTROL SWITCH DOOR CONTROL SWITCH ASSEMBLY DOOR LOCK SWITCH DOWNHILL ASSIST CONTROL SWITCH DRIVER SIDE AUTO SWITCH DRIVER SIDE DOWN SWITCH DRIVER SIDE UP SWITCH ECO MODE SWITCH ECO RUN CANCEL SWITCH ASSEMBLY ENGINE OIL PRESSURE SWITCH ASSEMBLY ENGINE SWITCH FOG LIGHT SWITCH FRONT PASSENGER SIDE CONTROL SWITCH FRONT WIPER DEICER SWITCH FRONT WIPER SWITCH FUEL LID COURTESY SWITCH FUEL LID OPENER SWITCH GLASS HATCH OPENER SWITCH ASSEMBLY HAZARD SWITCH HEADLIGHT DIMMER SWITCH ASSEMBLY HEATER SWITCH ASSEMBLY HORN SWITCH IGNITION OR STARTER SWITCH ASSEMBLY INTER LOCK SWITCH INTERLOCK SWITCH INTERMITTENT TIMING SWITCH LEFT FRONT DOOR COURTESY LIGHT SWITCH LEFT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY LEFT FRONT POWER SEAT SWITCH LEFT REAR DOOR COURTESY LIGHT SWITCH ASSEMBLY LEFT REAR SIDE CONTROL SWITCH LEFT SEAT HEATER SWITCH LEFT SEAT MEMORY SWITCH LEFT STEERING SWITCH LEVEL WARNING SWITCH ASSEMBLY LIGHT CONTROL SWITCH OUTER MIRROR HEATER SWITCH ASSEMBLY OUTER MIRROR SWITCH ASSEMBLY P POSITION DETECTION SWITCH PANORAMIC MOON ROOF CONTROL SWITCH PARK/ NEUTRAL POSITION SWITCH ASSEMBLY PARK/NEUTRAL POSITION SWITCH ASSEMBLY PARKING BRAKE SWITCH ASSEMBLY PATTERN SELECT SWITCH ASSEMBLY POWER SWITCH REAR WINDOW DEFOGGER SWITCH REAR WIPER SWITCH RIGHT FRONT DOOR COURTESY LIGHT SWITCH RIGHT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY RIGHT FRONT POWER SEAT SWITCH RIGHT REAR DOOR COURTESY LIGHT SWITCH ASSEMBLY RIGHT REAR SIDE CONTROL SWITCH RIGHT SEAT HEATER SWITCH RIGHT STEERING PAD SWITCH RIGHT STEERING SWITCH SEAT HEATER SWITCH SEAT VARIABLE CUSHION SWITCH STEERING HEATER SWITCH STEERING PAD SWITCH ASSEMBLY STOP LIGHT SWITCH ASSEMBLY SWITCH, HAZARD TEMPERATURE SWITCH TRANSMISSION CONTROL SWITCH TURN SIGNAL SWITCH UN-LOCK WARNING SWITCH ASSEMBLY UNLOCK WARNING SWITCH ASSEMBLY VACUUM WARNING SWITCH ASSEMBLY VIEW SWITCH VSC OFF SWITCH WASHER SWITCH WINDOW LOCK SWITCH WINDSHIELD WIPER SWITCH ASSEMBLY WIPER SWITCH

KEY INTER LOCK SOLENOID KEY INTERLOCK SOLENOID SHIFT LOCK SOLENOID VENT VALVE

(OR RED/ WIRE BLK WIRE BLK/DK GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE DK GRN WIRE GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE GRY WIRE IG PNK TILT WIRE LT BLU LT BLU WIRE LT BLU WIRE LT GRN WIRE MCI+ PNK MCI- WIRE MCO+ PNK MCO- WIRE MGC PNK WIRE NCA WIRE ORG/ WIRE ORG/BLK WIRE ORG/BLU WIRE ORG/GRY WIRE ORG/LT BLU WIRE ORG/LT GRN WIRE ORG/WHT WIRE PNK CANN WIRE PNK DATA WIRE PNK FUEL WIRE PNK HAZ WIRE PNK LIN 1 WIRE PNK PNK WIRE PNK RR- WIRE PNK SVPS WIRE PNK SWL WIRE PNK THA WIRE PNK VS WIRE PNK WIRE PNK/BLK WIRE PPL/BLK WIRE PPL/BLU WIRE PPL/GRN WIRE PPL/GRY WIRE PPL/LT BLU WIRE PPL/LT GRN WIRE PPL/ORG WIRE PPL/PNK ETM WIRE PPL/PNK WIRE PPL/RED WIRE PPL/VIO WIRE PPL/WHT WIRE PPL/YEL WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE SI PNK VS WIRE SWIL PNK WIRE THW PNK ETHW WIRE VIO WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/PPL WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/RED WIRE

2.7L 3.5L 2.7L 3.5L W/ REAR SEAT BENCH 1 2.7L, 3.5L HYBRID 2.7L, W/O MEMORY 3.5L 3.5L 2.7L 6 W/O STOP, START SYSTEM (CENTER (IF (LOWER REAR OF DRIVER'S DOOR (OR +BC +BM +BWP +SM A/C CONTROL ASSEMBLY A/C CONTROL ASSEMBLY 2 AIR CONDITIONING AIR CONDITIONING SYSTEM AIR CONDITIONING, COOLING FANS SYSTEMS AIR CONDITIONING, HEADLIGHTS SYSTEMS ANTI-THEFT SYSTEM ANTI-THEFT SYSTEMS ANTI-THEFT, DOOR LOCKS SYSTEMS AUTOMATIC A/C B+ BUS BBI+ BBL+ BBO- BBR+ BCB+ BCL+ BCR+ BCV- BD+2 BD- BD-2 BDL- BDSU OPEN BEHIND LEFT QUARTERPANEL) BRAKE CONTROL POWER SUPPLY ASSEMBLY BRAKE STROKE SIMULATOR CYLINDER SUB-ASSEMBLY BSL+ BSR+ BTH+ BUS - BUS G CA+ CAN I/F CAN JUNCTION TERMINAL 1 CAN L CANH CAN I/F CANL CB+ CDL+ CDR+ CENTER BUSBAR MODULE CENTER STOP LIGHT ASSEMBLY CHARGING SYSTEM CHG- I/F CJ CH CLEARANCE WARNING BUZZER 1 CLK+ CLOCK ASSEMBLY COMBINATION METER ASSEMBLY COMPRESSOR W/ PULLEY ASSEMBLY COMPUTER DATA COMPUTER DATA LINES COMPUTER DATA LINES SYSTEM CONTROL ASSEMBLY CONTROL CIRCUIT COOLER THERMISTOR 1 COOLING FANS SYSTEM COOLING FANS, AIR CONDITIONING SYSTEMS COS 1 CRUISE CONTROL SYSTEM CRUISE CONTROL, NAVIGATION SYSTEMS CSW+ CTR + CV+ DC- DEFOGGER SYSTEM DEFOGGER SYSTEM SEATS SYSTEM DETEC- DISPLAY DRIVER DISTANCE CONTROL DK+ DOOR CONTROL RECEIVER SUB-ASSEMBLY DOOR LOCKS DOOR LOCKS SYSTEM DOOR LOCKS, ANTI-THEFT SYSTEMS DOOR LOCKS, ANTI-THEFT, TRUNK, TAILGATE, FUEL DOORS SYSTEMS DRIVER DISPLAY DRIVER LED DRL OFF OFF DRL/PARKING LIGHT ECM 3.5L ECM SHIELD ECO MODE ECO RUN VEHICLE CONVERTER ASSEMBLY EL LFG ELECTRO MAGNETIC CONTROL COUPLING SUB-ASSEMBLY ELECTRONIC POWER STEERING SYSTEM EMP+ ETM- EV MODE EX+ EXCEPT HYBRID EXCEPT HYBRID HYBRID EXCEPT HYBRID HYBRID 2.7L 3.5L EXCEPT HYBRID HYBRID W/ HALOGEN W/ LED EXCEPT HYBRID HYBRID W/ STOP, START SYSTEM W/O STOP, START SYSTEM FANS SYSTEM FCP+ FLA- FLASH HIGH FLASHER CIRCUIT FP- FPD + FRCY CANL FRONT RECLINING FRONT SLIDE FRONT VERTICAL FRONT WIPER DEICER FRR+ FRV- FSW+ FUEL INJECTOR ASSEMBLY 1 FUEL INJECTOR ASSEMBLY 2 FUEL INJECTOR ASSEMBLY 3 FUEL INJECTOR ASSEMBLY 4 FUEL SENDER GAGE ASSEMBLY FUSIBLE LINK BLOCK ASSEMBLY FUSIBLE LINK MAIN GLOVE BOX LIGHT ASSEMBLY GND 2 GROUND DISTRIBUTION SYSTEM GSW 3 HEAD LIGHT/ DRL/PARKING LIGHT HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM COMPUTER DATA LINES SYSTEM HORNS SYSTEM HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START HOT W/ HTM- HYBRID EXCEPT HYBRID HYBRID EXCEPT HYBRID W/ NAVIGATION SYSTEM HYBRID EXCEPT HYBRID W/ STOP, START SYSTEM W/O STOP, START SYSTEM ICL- ICR+ IG 1 IGNITION KEY CYLINDER LIGHT IL+2 IL-2 INJECTOR DRIVER SHIELD INNER REAR VIEW MIRROR ASSEMBLY INSTRUMENT CLUSTER SYSTEM INSTRUMENT PANEL J/B ASSEMBLY INSTRUMENT PANEL PASSENGER AIR BAG W/O DOOR ASSEMBLY INTAKE MASS AIR FLOW METER SUB-ASSEMBLY INVERTER W/ CONVERTER ASSEMBLY JUNCTION TERMINAL KEY UNLOCK KLS+ LANE DEPARTURE WARNING LANE DEPARTURE WARNING BUZZER LANE DEPARTURE WARNING BUZZER, SKID CONTROL BUZZER ASSEMBLY LATCH) LCB+ LCV- LED DRIVER LEFT "C" PILLAR) LEFT AMBIENT LIGHT LEFT COURTESY LIGHT ASSEMBLY LEFT CURTAIN SHIELD AIR BAG ASSEMBLY LEFT CURTAIN SHIELD AIRBAG ASSEMBLY LEFT FOG LIGHT ASSEMBLY LEFT FRONT AMBIENT ILLUMINATION LEFT FRONT SEAT AIR BAG ASSEMBLY LEFT FRONT SEAT INNER BELT ASSEMBLY LEFT FRONT SEAT OUTER BELT ASSEMBLY LEFT FRONT SPOT LIGHT ASSEMBLY LEFT LICENSE PLATE LIGHT ASSEMBLY LEFT OUTER REAR VIEW MIRROR ASSEMBLY LEFT QUARTERPANEL) LEFT REAR 2 SEAT BELT ASSEMBLY LEFT REAR AMBIENT ILLUMINATION LEFT REAR COMBINATION LIGHT ASSEMBLY LEFT REAR INNER SEAT BELT ASSEMBLY 2 LEFT REAR LIGHT ASSEMBLY LEFT REAR SEAT 3 POINT BELT ASSEMBLY LEFT REAR SEAT 3 POINT TYPE BELT ASSEMBLY LEFT REAR SEAT BELT ASSEMBLY 2 LEFT REAR SEAT POINT TYPE BELT ASSEMBLY 3 LEFT REAR SPOT LIGHT ASSEMBLY LEFT SEAT BACK CLIMATE CONTROL BLOWER LEFT SEAT CUSHION CLIMATE CONTROL BLOWER ASSEMBLY LEFT TURN IND LEFT UP LEFT VISOR ASSEMBLY LFT- LH BUSBAR MODULE LIGHT CONTROL LIN 1 LIN SLR+ LINES SYSTEM LO HI LOWER INSTRUMENT PANEL AIR BAG ASSEMBLY 1 LSP + LSWR 3 4 MAIN FUSIBLE LINK MAP LIGHT ASSEMBLY MCI- MCO- MEMORY SYSTEM MEMORY SYSTEMS MEMORY, WARNING, TRUNK, TAILGATE, FUEL DOORS, SEATS, SOUND SYSTEMS MG+ MIRRORS SYSTEM MIRRORS, NAVIGATION, CRUISE CONTROL, SOUND, COMPUTER DATA LINES SYSTEMS MIST OFF MOP+ MSM+ MTH+ NAVIGATION RECEIVER ASSEMBLY NAVIGATION SYSTEM NAVIGATION, MEMORY, WARNING, TRUNK, TAILGATE, FUEL DOORS, SOUND SYSTEMS NAVIGATION, SOUND SYSTEMS NAVIGATION, SOUND SYSTEMS HEADLIGHTS SYSTEM NE+ NS+ OF DASH) OFF DRL OFF OFF HOOK OFF HOOK VOLUME+ ON HOOK ON HOOK SEEK- ON OFF ON- OFF +RES P-AB PASSENGER AIR BAG ON/OFF IND PL- POWER BACK DOOR WARNING BUZZER POWER DISTRIBUTION SYSTEM POWER TOPS SYSTEM POWER TOPS, POWER WINDOWS SYSTEMS POWER WINDOWS SYSTEM POWER WINDOWS, DEFOGGER, MEMORY SYSTEMS POWER WINDOWS, MEMORY SYSTEMS PPL EHT PPL FE PR- PRR- PUDDLE LIGHT PURGE VSV PWS FRCY FLCY R-U R-V R-W R/B 5 R/B 6 RADIO, DISPLAY RECEIVER ASSEMBLY RBBU RBUG RCB+ RCL- REAR PASSENGER'S SEAT BELT WARNING LIGHT IND REAR WINDOW DEFOGGER REQ+ RH BUSBAR MODULE RIGHT AMBIENT LIGHT RIGHT COURTESY LIGHT ASSEMBLY RIGHT CURTAIN SHIELD AIR BAG ASSEMBLY RIGHT CURTAIN SHIELD AIRBAG ASSEMBLY RIGHT DOWN RIGHT END OF DASH) RIGHT FOG LIGHT ASSEMBLY RIGHT FRONT AMBIENT ILLUMINATION RIGHT FRONT SEAT AIR BAG ASSEMBLY RIGHT FRONT SEAT AIR BAG SUB-ASSEMBLY RIGHT FRONT SEAT INNER BELT ASSEMBLY RIGHT FRONT SEAT OUTER BELT ASSEMBLY RIGHT FRONT SPOT LIGHT ASSEMBLY RIGHT LEFT RIGHT LICENSE PLATE LIGHT ASSEMBLY RIGHT OUTER REAR VIEW MIRROR ASSEMBLY RIGHT REAR 2 SEAT BELT ASSEMBLY RIGHT REAR AMBIENT ILLUMINATION RIGHT REAR COMBINATION LIGHT ASSEMBLY RIGHT REAR INNER SEAT BELT ASSEMBLY 2 RIGHT REAR LIGHT ASSEMBLY RIGHT REAR SEAT 3 POINT BELT ASSEMBLY RIGHT REAR SEAT 3 POINT TYPE BELT ASSEMBLY RIGHT REAR SEAT BELT ASSEMBLY 2 RIGHT REAR SPOT LIGHT ASSEMBLY RIGHT SEAT BACK CLIMATE CONTROL BLOWER RIGHT SEAT CUSHION CLIMATE CONTROL BLOWER ASSEMBLY RIGHT TURN IND RIGHT VISOR ASSEMBLY RLA- RLID IND RLR+ ROOM LIGHT ASSEMBLY 1 RRA+ RRR + SEATS SYSTEM SEATS, MEMORY SYSTEMS SEATS, WIPER/ WASHER SYSTEMS SECURITY IND SEEK- MODE SELECTABLE FORCE LIMITER SERVICE PLUG SET- SFL- SFR- SG-2 SG-4 SG-5 SG-6 SHIFT INTERLOCK SYSTEM SHIFT INTERLOCK, ANTI-THEFT SYSTEMS SKID CONTROL BUZZER ASSEMBLY SL- SLC+ SLIDING ROOF SLS+ SLT- SLU+ SMART DOOR CONTROL RECEIVER ASSEMBLY SOL + SOUND SYSTEMS SOUND, MEMORY, NAVIGATION SYSTEMS SOUND, NAVIGATION SYSTEMS SP- SPI+ SPO- SR- SSR+ STARTING CIRCUIT STARTING/ CHARGING SYSTEM STARTING/ CHARGING, ELECTRONIC POWER STEERING SYSTEMS STARTING/CHARGING SYSTEM STARTING/CHARGING, NAVIGATION SYSTEMS STEREO COMPONENT TUNER ASSEMBLY STEREO JACK ADAPTER ASSEMBLY 1 STP 1 SUPPLEMENTAL RESTRAINTS SYSTEM SUPPLEMENTAL RESTRAINTS, WARNING SYSTEMS SW 1 TAIL OFF DRL OFF TELEPHONE MICROPHONE ASSEMBLY TELEVISION DISPLAY ASSEMBLY THR+ TRAILER TOW CIRCUIT TRANSMISSION FLOOR SHIFT ASSEMBLY TRANSMISSIONS SYSTEM TRN+ TRUNK, TAILGATE, FUEL DOORS SYSTEM TRUNK, TAILGATE, FUEL DOORS, ANTI-THEFT, DOOR LOCKS SYSTEMS TRUNK, TAILGATE, FUEL DOORS, DOOR LOCKS, ANTI-THEFT SYSTEMS TRUNK, TAILGATE, FUEL DOORS, DOOR LOCKS, WARNING SYSTEMS TURN LIGHT TURN SIGNAL TWL- TWR+ UNLOCK DETECTION USA CANADA USA CANADA W/O STOP, START SYSTEM USA CANADA W/O STOP, START SYSTEM W/ STOP, START SYSTEM VL HL VOICE VOLUME- VOLTAGE INVERTER ASSEMBLY VV- VVE- VVI+ VVL+ VVR+ W/0 GLASS HATCH OPENER W/ BLIND SPOT MONITOR, PRE-COLLISION SYSTEM, BACK GUIDE MONITOR SYSTEM W/ CLIMATE CONTROL SEAT W/ FOG LIGHT W/ GLASS HATCH OPENER W/ LED W/ MEMORY W/ MEMORY W/O MEMORY W/ MEMORY, POWER BACK DOOR W/ NAVIGATION W/ NAVIGATION SYSTEM W/ NAVIGATION W/O NAVIGATION W/ POWER BACK DOOR W/O POWER BACK DOOR W/ PANORAMIC VIEW MONITOR W/ PANORAMIC VIEW MONITOR SYSTEM W/O PANORAMIC VIEW MONITOR SYSTEM W/ PARKING LIGHT LED W/ POWER BACK DOOR W/O POWER BACK DOOR W/ REAR SEAT BENCH 1 W/ REAR POWER WINDOW JAM PROTECTION W/ REAR POWER WINDOW JAM PROTECTION W/O REAR POWER WINDOW JAM PROTECTION W/ REAR SEAT BENCH 1 W/ REAR SEAT ENTERTAINMENT SYSTEM W/ SAFETY CONNECT W/ SMART KEY SYSTEM W/O SMART KEY SYSTEM W/ START/ STOP SYSTEM W/ STOP, START SYSTEM W/O STOP, START SYSTEM W/ STOP, START SYSTEM W/O STOP, START SYSTEM HYBRID EXCEPT HYBRID W/ STOP, START SYSTEM W/O STOP, START SYSTEM W/O MEMORY W/ MEMORY W/ STOP/ START SYSTEM W/ TIRE PRESSURE WARNING SYSTEM W/O CLIMATE CONTROL SEAT W/O CLIMATE CONTROL SEAT W/ CLIMATE CONTROL SEAT W/O CLIMATE CONTROL SEAT W/ REAR POWER WINDOW JAM PROTECTION W/O GLASS HATCH OPENER W/O MEMORY W/O MEMORY W/O REAR POWER WINDOW JAM PROTECTION W/O NAVIGATION W/O NAVIGATION SYSTEM W/O NAVIGATION SYSTEM W/ NAVIGATION SYSTEM W/O NAVIGATION W/ NAVIGATION W/O PANORAMIC VIEW MONITOR SYSTEM W/O POWER BACK DOOR W/ POWER BACK DOOR EXCEPT HYBRID HYBRID W/O POWER BACK DOOR W/ POWER BACK DOOR W/O MEMORY W/ MEMORY W/O REAR POWER WINDOW JAM PROTECTION W/O SAFETY CONNECT W/O SAFETY CONNECT W/ SAFETY CONNECT W/O SEAT VARIABLE CUSHION W/ SEAT VARIABLE CUSHION W/O SMART KEY SYSTEM W/ SMART KEY SYSTEM W/O STOP, START SYSTEM W/ STOP, START SYSTEM W/O STOP, START SYSTEM W/ STOP, START SYSTEM W/ REAR SEAT BENCH 1 W/O STOP/ START SYSTEM W/O TIRE PRESSURE WARNING SYSTEM W/O TIRE PRESSURE WARNING SYSTEM, SMART KEY SYSTEM W/O TIRE PRESSURE WARNING SYSTEM, W/ SMART KEY SYSTEM WARNING SYSTEM WARNING SYSTEMS WARNING, DOOR LOCKS, ANTI-THEFT SYSTEMS WARNING, SUPPLEMENTAL RESTRAINTS SYSTEMS WATER INLET W/ THERMOSTAT SUB-ASSEMBLY WIPER/WASHER SYSTEM WIPER/WASHER, SEATS SYSTEMS
