Toyota Highlander III (2013-2016) w/o smart key system w/ smart key system Wiring diagram

AIR BAG SENSOR ASSEMBLY BACK DOOR CONTROL SWITCH BACK DOOR LOCK ASSEMBLY BACK DOOR OPENER SWITCH ASSEMBLY BLK WIRE BLK/ WHT WIRE BRN WIRE COMBINATION METER ASSEMBLY FE (RIGHT CENTER OF DASH) FROM GROUND FC (DIAGRAM 2 OF 6) HA (TOP OF LEFT "D" PILLAR) IA (BASE OF LEFT "B" PILLAR) INSTRUMENT PANEL J/B MAIN (BEHIND LEFT BODY ECU END OF DASH) J/C 11 (RIGHT REAR CORNER OF CARGO AREA) J/C 14 (UNDER FRONT PASSENGER SEAT) J/C 3 (LEFT SIDE OF DASH) J/C 9 (LEFT CENTER OF DASH) LA (RIGHT "B" PILLAR) LEFT LICENSE LEFT PLATE REAR LIGHT LIGHT ASSEMBLY ASSEMBLY MULTIPLEX NETWORK DOOR ECU NETWORK GATEWAY ECU PPL REAR BLOWER MOTOR W/ FAN SUB-ASSEMBLY RED WIRE RIGHT FRONT POWER SEAT SWITCH RIGHT REAR DOOR LOCK W/ MOTOR ASSEMBLY RIGHT REAR LIGHT ASSEMBLY RIGHT REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY RIGHT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY RIGHT SEAT CUSHION CLIMATE CONTROL BLOWER ASSEMBLY RIGHT SEAT HEATER CONTROL SUB-ASSEMBLY SPIRAL CABLE ASSEMBLY (IN STEERING COLUMN) STEERING PAD SWITCH ASSEMBLY STEERING SENSOR TO GROUND MC (DIAGRAM 4 OF 6) W/ CLIMATE CONTROL SEAT W/ REAR POWER WINDOW JAM PROTECTION W/O CLIMATE CONTROL SEAT W/O NAVIGATION W/O NAVIGATION W/ NAVIGATION W/O REAR POWER WINDOW JAM PROTECTION W/O SMART KEY SYSTEM W/ SMART KEY SYSTEM WHT/ BLK WIRE WHT/BLK WIRE XA (LEFT SIDE OF BACK DOOR)
