Toyota Highlander III (2013-2016) w/o blindspot monitor system Wiring diagram
This page shows the only wiring diagram for the component.w/o blindspot monitor system, which is found in the car Toyota Highlander III (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o blindspot monitor system (1 of 1)
13 26 CANH CANL
15 5 PNK WIRE
2 1 PNK WIRE
2 6 CAN- CAN+ PNK WIRE
4 8 CANH CANL
5 6 CANL CANH
6 14 CANH CANL
AIR BAG SENSOR ASSEMBLY (UNDER FRONT OF CENTER CONSOLE)
BLK WIRE
BLU WIRE
BRN WIRE
CAN JUNCTION CONNECTOR 1 (LEFT CENTER OF DASH)
CAN JUNCTION CONNECTOR 3 (LEFT CENTER OF DASH)
CAN JUNCTION CONNECTOR 4 (CENTER OF DASH)
CERTIFICATION ECU (W/ SMART KEY SYSTEM) (BEHIND RIGHT SIDE OF DASH)
DATA LINK CONNECTOR (LEFT SIDE OF ENGINE COMPT) 13 3
ECM (LEFT SIDE OF ENGINE COMPT)
ENGINE ROOM R/B 1 (LEFT SIDE OF ENGINE COMPT)
GBSI
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH)
JUNCTION CONNECTOR 4 (RIGHT SIDE OF DASH)
LT BLU WIRE
LT GRN WIRE
MILLIMETER WAVE RADAR SENSOR ASSEMBLY (FRONT CENTER OF ENGINE COMPT)
MPX-B 1 FUSE
NETWORK GATEWAY ECU (RIGHT SIDE OF DASH)
ORG/ WIRE
PNK WIRE
POWER STEERING ECU ASSEMBLY (BEHIND LEFT SIDE OF DASH)
RED WIRE
STEERING SENSOR (IN STEERING COLUMN)
VIO WIRE
W/ BLINDSPOT MONITOR SYSTEM
W/O BLINDSPOT MONITOR SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Body ecu circuit, except hybrid (2 of 3) -> W/O BLINDSPOT MONITOR SYSTEM
