Toyota Highlander III (2013-2016) window regulator switch assembly (w/o rear power window jam Wiring diagram
This page shows the only wiring diagram for the component.window regulator switch assembly (w/o rear power window jam, which is found in the car Toyota Highlander III (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram window regulator switch assembly (w/o rear power window jam (1 of 1)
ASSEMBLY
BLK WIRE
DIFFERENTIAL LOCK SWITCH (EXCEPT HYBRID)
DOWNHILL ASSIST CONTROL SWITCH VSC OFF SWITCH
EXCEPT HYBRID
EXCEPT HYBRID HYBRID
FROM J/C 5 (DIAGRAM 1 OF 3)
FROM J/C 5 (DIAGRAM 2 OF 3)
HEATER SWITCH ASSEMBLY (HYBRID)
J/C 5 (CENTER
J/C 5 (CENTER OF DASH)
LEFT SEAT HEATER SWITCH (W/ SEAT HEATER, W/O CLIMATE CONTROL SEAT)
LEFT SEAT MEMORY SWITCH (W/ SEAT POSITION MEMORY)
LILL
LT BLU WIRE
LT GRN WIRE
MAP LIGHT ILL ASSEMBLY
OF DASH)
ORG/ WIRE
OUTER MIRROR SWITCH ASSEMBLY (W/ SEAT POSITION MEMORY)
OUTER MIRROR SWITCH ASSEMBLY (W/O SEAT POSITION MEMORY)
PATTERN SELECT SWITCH
PROTECTION)
RED WIRE
RIGHT FRONT POWER WINDOW REGULATOR SWITCH ASSEMBLY
RIGHT REAR POWER
RIGHT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY
RIGHT SEAT HEATER SWITCH (W/ SEAT HEATER, W/O CLIMATE CONTROL SEAT)
SEAT HEATER SWITCH (W/O SEAT HEATER, CLIMATE CONTROL SEAT)
SHIFT ILL+ POSITION INDICATOR
TO J/C 5 (DIAGRAM 2 OF 3)
W/ REAR POWER WINDOW JAM PROTECTION
WHT WIRE
WINDOW REGULATOR SWITCH ASSEMBLY (W/O REAR POWER WINDOW JAM
YEL WIRE
Go to component -> Instrument illumination circuit (2 of 3) -> WINDOW REGULATOR SWITCH ASSEMBLY (W/O REAR POWER WINDOW JAM
