Toyota Highlander III (2013-2016) switch turn signal Wiring diagram
This page shows the only wiring diagram for the component.switch turn signal, which is found in the car Toyota Highlander III (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram switch turn signal (1 of 1)
+ECU
14 13 CANH CANL COMPUTER DATA LINES SYSTEM
7 11 GND TRNI
AB (HYBRID) (LEFT FRONT OF ENGINE COMPT)
ALT FUSE
ASSEMBLY
AUTO
BLK WIRE
BLU WIRE
BRN WIRE
CANADA
CENTER STOP LIGHT) (BASE OF LEFT "D" PILLAR)
CONTROL ECU
DC/DC FUSE
DRL OFF OFF
ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT)
FA (LEFT SIDE OF DASH)
FB (UNDER FRONT OF CENTER CONSOLE)
FC (RIGHT KICK PANEL)
FUSE
GRN WIRE
GROUND J/C 4 (RIGHT FRONT OF ENGINE COMPT)
GRY WIRE
HEADLIGHT DIMMER SWITCH ASSEMBLY
HOT AT ALL TIMES
HOT W/ ACC RELAY ENERGIZED
INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH)
J/C 9 (LEFT CENTER OF DASH)
LB (RIGHT REAR QUARTERPANEL)
LEFT
LEFT HEADLIGHT ASSEMBLY
LEFT OUTER REARVIEW MIRROR ASSEMBLY
LEFT REAR COMBINATION LIGHT ASSEMBLY TL
LT BLU WIRE
LT GRN WIRE
MAIN BODY ECU (ON INSTRUMENT PANEL J/B)
MARKER
MB (LEFT "C" PILLAR)
MC (LEFT REAR QUARTERPANEL)
NOISE FILTER (REAR WINDOW DEFOGGER)
ORG/ WIRE
PANEL FUSE
PARKING
PNK WIRE
PPL 11 31
PPL/YEL WIRE
RED WIRE
RELAY ENERGIZED
RIGHT
RIGHT HEADLIGHT ASSEMBLY
RIGHT OUTER REARVIEW MIRROR ASSEMBLY
RIGHT REAR COMBINATION LIGHT ASSEMBLY
STOP
STP EXCEPT HYBRID
SWITCH LIGHT CONTROL
SWITCH TURN SIGNAL
TAIL
TAIL FUSE
TAIL RELAY
TAIL/SIDE
TL STP
TURN
USA
VIO WIRE
W/ MEMORY
W/O MEMORY
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> SWITCH TURN SIGNAL
