Toyota Highlander III (2013-2016) pnk eppm ppmp Wiring diagram
This page shows the only wiring diagram for the component.pnk eppm ppmp, which is found in the car Toyota Highlander III (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk eppm ppmp (1 of 1)
A/F EFI 2 HTR FUSE FUSE
A/F HTR 2 FUSE
A/F RELAY
ACCELERATOR PEDAL SENSOR ASSEMBLY (ON ACCELERATOR PEDAL BRACKET)
ANTI-THEFT SYSTEM
BLK WIRE
BLU WIRE
BRN WIRE
C/OPN RELAY
CANH EC
COMPUTER DATA LINES SYSTEM
COOLING FANS SYSTEM
CRUISE CONTROL SYSTEM
ECM (LEFT SIDE OF ENGINE COMPT)
EFI 3 FUSE
EFI FUSE
EFI MAIN FUSE
EFI MAIN RELAY
ENGINE ROOM R/B 1
FB (UNDER FRONT OF CENTER CONSOLE)
FC STA TC
FUEL SUCTION TUBE W/ PUMP, GAUGE ASSEMBLY (IN FUEL TANK)
GAUGE
GRN WIRE
GROUND J/C 1
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT)
IDLE UP FUSE
IMI IMO
INSTRUMENT CLUSTER SYSTEM
LT BLU WIRE
LT GRN WIRE
MA (IN LEFT REAR DOOR)
ORG/ WIRE
PNK 15 16 17 WIRE
PNK EPPM PPMP WIRE
RED WIRE
RELAY ENERGIZED
SEMICONDUCTOR POWER INTEGRATION ECU RDEF
SFTD
SFTU
SFTU SFTD RFC
SNWI MPMP
STARTING/CHARGING SYSTEM COMPUTER DATA LINES SYSTEM
TACH
TRANSMISSION CONTROL SWITCH (UNDER CENTER CONSOLE)
VCPP
VIO WIRE
VPA EPA VCPA
VPMP
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 2.7l (1 of 5) -> PNK EPPM PPMP WIRE
