Toyota Highlander III (2013-2016) mpx-b 1 fuse radio fuse Wiring diagrams
This page contains all the electrical diagrams for the component. mpx-b 1 fuse radio fuse, in which he is found in the car Toyota Highlander III (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram mpx-b 1 fuse radio fuse (1 of 2)
3.5L
A/F HTR FUSE
A/F RELAY
ABS 1 FUSE ABS 2 FUSE
ALT FUSE
ANTI-LOCK BRAKES SYSTEM DOOR LOCKS, ANTI-THEFT SYSTEMS
BATT ALT
BATTERY
BLK WIRE
BLU WIRE
EFI 1 FUSE
EFI MAIN FUSE
EFI MAIN RELAY
ENGINE CONTROLS SYSTEM
ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT)
ETCS FUSE
FAN 1 FUSE
FROM
FROM ECTS FUSE (DIAGRAM 1 OF 4)
FROM INSTRUMENT PANEL J/B (DIAGRAM 2 OF 4)
FUSE
FUSE (DIAGRAM 1 OF 4)
GRN WIRE
GRY WIRE
H-LP H-LP LO LH FUSE LO RH FUSE
H-LP H-LP RH-LO LH-LO RELAY RELAY
HORN FUSE TOWING FUSE
HORNS EXTERIOR SYSTEM LIGHTS SYSTEM
INJ FUSE
J/B-B FUSE
J/C 2 (LEFT SIDE OF ENGINE COMPT)
LOCK
LOCK LOCK ON ON OFF OFF
LT BLU WIRE
LT GRN WIRE
MAIN EPS FUSE AMP 1 FUSE AMP 2 FUSE MAYDAY FUSE FUSE
MAIN FUSIBLE LINK
MPX-B 1 FUSE RADIO FUSE
NAVIGATION ELECTRONIC SOUND, SYSTEM POWER NAVIGATION STEERING SYSTEMS SYSTEM
NAVIGATION, SOUND SYSTEMS
ODS FUSE
ON LOCK OFF
ORG/ WIRE
RED WIRE
S-HORN FUSE
SEMICONDUCTOR POWER INTEGRATION ECU
SHORT
ST FUSE ALT-S FUSE
STARTING/ CHARGING SYSTEM
STARTING/ STARTING/ CHARGING CHARGING SYSTEM SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM
TO ENGINE ROOM R/B 1 (DIAGRAM 1 OF 4)
TO HORN FUSE (DIAGRAM 1 OF 4)
TO HTR FUSE (DIAGRAM 4 OF 4)
TO INSTRUMENT PANEL J/B (DIAGRAM 2 OF 4)
TO INSTRUMENT PANEL J/B (DIAGRAM 3 OF 4)
TO INSTRUMENT PANEL J/B (DIAGRAM 4 OF 4)
VIO WIRE
W/ SMART KEY SYSTEM W/O SMART KEY SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, except hybrid (1 of 4) -> MPX-B 1 FUSE RADIO FUSE
Wiring diagram mpx-b 1 fuse radio fuse (2 of 2)
A/C W/PMP FUSE
A/F HTR FUSE
A/F RELAY
ABS ABS MAIN 3 FUSE MTR 2 FUSE
ABS J/B-B FUSE MTR 1 FUSE
ABS MAIN 2 FUSE
AIR CONDITIONING, COOLING FANS SYSTEMS
ALT
AMP 1 FUSE TOWING FUSE AMP 2 FUSE
ANTI-LOCK BRAKES SYSTEM
BATT FAN FUSE
BATTERY
BLK WIRE
BLU WIRE
CAPACITOR FUSE
DC/DC FUSE
DC/DC-S FUSE
DOOR LOCKS, ANTI-THEFT SYSTEMS SUPPLEMENTAL RESTRAINTS SYSTEM
EFI 1 FUSE
EFI MAIN FUSE
EFI MAIN RELAY
ELECTRONIC POWER STEERING SYSTEM AIR CONDITIONING SYSTEM
ENGINE CONTROLS SYSTEM
ENGINE CONTROLS, TRANSMISSIONS SYSTEMS
ENGINE ENGINE CONTROLS, CONTROLS COOLING SYSTEM FANS SYSTEMS
ENGINE ROOM J/B 1 (LEFT SIDE OF ENGINE COMPT)
ENGINE ROOM R/B 3 (LEFT SIDE ABS OF ENGINE MAIN 1 COMPT) FUSE IGCT RELAY
EPS FUSE
ETCS FUSE
EXTERIOR SOUND, LIGHTS NAVIGATION SYSTEM SYSTEMS
FAN 1 FUSE
FROM
FROM ECTS FUSE (DIAGRAM 1 OF 4)
FROM INSTRUMENT PANEL J/B (DIAGRAM 2 OF 4)
FUSE
FUSE (DIAGRAM 1 OF 4)
FUSIBLE LINK BLOCK ASSEMBLY (LEFT REAR MAIN OF CARGO FUSE AREA)
GRN WIRE
GRY WIRE
H-LP H-LP RH-LO LH-LO RELAY RELAY
H-LP LH LO H-LP RH LO FUSE
HORN FUSE
HORNS SYSTEM
INJ FUSE
LT BLU WIRE
LT GRN WIRE
MAIN MAYDAY FUSE FUSE
MPX-B 1 FUSE RADIO FUSE
NAVIGATION SYSTEM
NAVIGATION, SOUND SYSTEMS
ODS FUSE S HORN FUSE
OIL PMP FUSE
ORG/ WIRE
PNK WIRE
R/B 3 FUSE
RED WIRE
SEMICONDUCTOR POWER INTEGRATION ECU
SHORT
TO HORN FUSE (DIAGRAM 1 OF 4)
TO HTR FUSE (DIAGRAM 4 OF 4)
TO INSTRUMENT PANEL J/B (DIAGRAM 2 OF 4)
TO INSTRUMENT PANEL J/B (DIAGRAM 3 OF 4)
TO INSTRUMENT PANEL J/B (DIAGRAM 4 OF 4)
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, hybrid (1 of 4) -> MPX-B 1 FUSE RADIO FUSE
