Toyota Highlander III (2013-2016) left seat heater control sub-assembly Wiring diagrams

This page contains all the electrical diagrams for the component. left seat heater control sub-assembly, in which he is found in the car Toyota Highlander III (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram left seat heater control sub-assembly (1 of 3)

Wiring diagram left seat heater control sub-assembly for Toyota Highlander III (2013-2016) (1 of 3)

Get access

10 23 19 9 18 SVDB SG-6 SVPS 5 4 3 2 1 SI VS IGB PNK WIRE A/C AMPLIFIER (BEHIND RIGHT SIDE OF DASH) BLK WIRE BLLH BLRH BLU WIRE ECU-IG FUSE FB (UNDER FRONT OF CENTER CONSOLE) GND 2 GRN WIRE GRY WIRE IGB INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH) J/C 14 (UNDER FRONT PASSENGER SEAT) J/C 15 (UNDER DRIVER SEAT) J/C 15 (UNDER DRIVER SEAT) INTERIOR HYBRID EXCEPT HYBRID 24 22 LIGHTS SYSTEM J/C 16 (UNDER DRIVER SEAT) LA (RIGHT "B" PILLAR) LEFT SEAT BACK CLIMATE CONTROL BLOWER LEFT SEAT CUSHION CLIMATE CONTROL BLOWER ASSEMBLY LEFT SEAT HEATER CONTROL SUB-ASSEMBLY LT BLU WIRE LT GRN WIRE MB (LEFT "C" PILLAR) ORG/ WIRE PNK SVPS WIRE PNK VS WIRE PNK WIRE RED WIRE RELAY ENERGIZED RIGHT SEAT BACK CLIMATE CONTROL BLOWER RIGHT SEAT CUSHION CLIMATE CONTROL BLOWER ASSEMBLY RIGHT SEAT HEATER CONTROL SUB-ASSEMBLY S/HTR F/L FUSE S/HTR F/R FUSE SEAT BACK HEATER SEAT CUSHION HEATER SEAT HEATER CONTROL SEAT HEATER SWITCH SEAT SEAT CUSHION BACK HEATER HEATER SHIN SVPB SVSG SWR THL SHIN SWL 9 14 8 THR+ VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Front heated seats circuit, with climate control seat -> LEFT SEAT HEATER CONTROL SUB-ASSEMBLY

Wiring diagram left seat heater control sub-assembly (2 of 3)

Wiring diagram left seat heater control sub-assembly for Toyota Highlander III (2013-2016) (2 of 3)

Get access

5 6 EXCEPT HYBRID HYBRID A/C AMPLIFIER ASSEMBLY (HYBRID) (BEHIND RIGHT SIDE OF DASH) BRN WIRE ECU-IG FUSE EXCEPT HYBRID FB (UNDER FRONT OF CENTER CONSOLE) GRN WIRE GRY WIRE INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH) J/C 15 (UNDER DRIVER SEAT) LA (RIGHT "B" PILLAR) LEFT SEAT HEATER CONTROL SUB-ASSEMBLY LEFT SEAT HEATER SWITCH LT BLU WIRE LT GRN WIRE MB (LEFT "C" PILLAR) ORG/ WIRE RED WIRE RELAY ENERGIZED RIGHT SEAT HEATER CONTROL SUB-ASSEMBLY RIGHT SEAT HEATER SWITCH S/HTR F/L FUSE S/HTR F/R FUSE SEAT BACK HEATER SEAT CUSHION HEATER SEAT HEATER CONTROL SHIN SWL 1 6 SWR THL THR+ VIO WIRE WHT WIRE WHT/BLK WIRE

Go to component -> Front heated seats circuit, without climate control seat -> LEFT SEAT HEATER CONTROL SUB-ASSEMBLY

Wiring diagram left seat heater control sub-assembly (3 of 3)

Wiring diagram left seat heater control sub-assembly for Toyota Highlander III (2013-2016) (3 of 3)

Get access

A/C CONTROL ASSEMBLY 2 BLK WIRE COM FA (LEFT SIDE OF DASH) GRN WIRE GRY WIRE LB (RIGHT REAR QUARTERPANEL) LEFT SEAT HEATER CONTROL SUB-ASSEMBLY MB (LEFT "C" PILLAR) PNK SWL WIRE PNK WIRE PWR RELAY ENERGIZED RELAY ENERGIZED INSTRUMENT PANEL J/B ECU-IG FUSE (BEHIND LEFT END OF DASH) RIGHT SEAT HEATER CONTROL SUB-ASSEMBLY RLY S/HTR RR FUSE SEAT BACK HEATER SEAT CUSHION HEATER SEAT HEATER CONTROL SEAT HEATER SWITCH THL THR+ VIO WIRE WHT WIRE WHT/BLK WIRE

Go to component -> Rear heated seats circuit -> LEFT SEAT HEATER CONTROL SUB-ASSEMBLY

Toyota Highlander III (2013-2016) left seat heater control sub-assembly Wiring diagrams

Wiring diagram left seat heater control sub-assembly (1 of 3)

List of components:

Wiring diagram left seat heater control sub-assembly (2 of 3)

List of components:

Wiring diagram left seat heater control sub-assembly (3 of 3)

List of components:
