Toyota Highlander III (2013-2016) left front power window regulator motor assembly Wiring diagrams

This page contains all the electrical diagrams for the component. left front power window regulator motor assembly, in which he is found in the car Toyota Highlander III (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

left front power window regulator motor assembly wiring diagram (1 of 4)

A/C CONTROL ASSEMBLY 2 ALL DR LOCK RELAY ASSEMBLY BRN WIRE CENTER POWER OUTLET SOCKET ASSEMBLY DOOR CONTROL SWITCH DOOR CONTROL SWITCH ASSEMBLY DOOR L/D-DR D-DR BACK UNLOCK UNLOCK RELAY RELAY RELAY FA (LEFT SIDE OF DASH) FROM GROUND FB (DIAGRAM 5 OF 6) FUEL LID OPENER SWITCH GLASS ROOF CONTROL ECU (SLIDING ROOF DRIVE GEAR ASSEMBLY) GLOVE BOX LIGHT ASSEMBLY LEFT FRONT DOOR LOCK W/ MOTOR ASSEMBLY LEFT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY LEFT RIGHT VISOR VISOR ASSEMBLY ASSEMBLY POWER OUTLET SOCKET ASSEMBLY 1 POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY PPL PRE-COLLISION SYSTEM CANCEL SWITCH ASSEMBLY REAR POWER OUTLET SOCKET ASSEMBLY 1 ROOF SUNSHADE CONTROL ECU (SLIDING ROOF DRIVE GEAR ASSEMBLY) SLIDING ROOF CONTROL ECU (SLIDING ROOF DRIVE GEAR ASSEMBLY) WHT WIRE WHT/BLK WIRE

Go to component -> Ground distribution circuit, except hybrid (6 of 6) -> LEFT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY

left front power window regulator motor assembly wiring diagram (2 of 4)

A/C CONTROL ASSEMBLY 2 ALL DR LOCK RELAY BRN WIRE CENTER POWER OUTLET SOCKET ASSEMBLY D DR UNLOCK RELAY DOOR CONTROL SWITCH DOOR CONTROL SWITCH ASSEMBLY FA (LEFT SIDE OF DASH) FROM GROUND FB (DIAGRAM 5 OF 6) FUEL LID OPENER SWITCH GLASS ROOF CONTROL ECU (SLIDING ROOF DRIVE GEAR ASSEMBLY) GLOVE BOX LIGHT ASSEMBLY JAM PROTECTION W/ DYNAMIC RADAR CRUISE CONTROL L/D-DR UNLOCK RELAY LEFT FRONT DOOR LOCK W/ MOTOR ASSEMBLY LEFT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY LEFT RIGHT VISOR VISOR ASSEMBLY ASSEMBLY POWER MANAGEMENT CONTROL ECU POWER OUTLET SOCKET ASSEMBLY 1 POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY PPL PRE-COLLISION SYSTEM CANCEL SWITCH ASSEMBLY REAR POWER OUTLET SOCKET ASSEMBLY 1 ROOF SUNSHADE CONTROL ECU (SLIDING ROOF DRIVE GEAR ASSEMBLY) SLIDING ROOF CONTROL ECU (SLIDING ROOF DRIVE GEAR ASSEMBLY) STEERING LOCK ACTUATOR ASSEMBLY TIRE PRESSURE WARNING RESET SWITCH (TIRE PRESSURE WARNING SWITCH 1) VEHICLE APPROACHING SPEAKER CONTROLLER WHT/BLK WIRE

Go to component -> Ground distribution circuit, hybrid (6 of 6) -> LEFT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY

left front power window regulator motor assembly wiring diagram (3 of 4)

A/C FUSE AUTO BLK WIRE BLU WIRE DOWN FA (LEFT SIDE OF DASH) FC (RIGHT KICK PANEL) FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH) J/C 10 (CENTER OF DASH) J/C 8 (RIGHT END OF DASH) LEFT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY LIN LT BLU WIRE LT GRN WIRE P/W (RL) FUSE P/W F/L P/W F/R P/W RR PNK WIRE POWER RELAY POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY PPL/GRN WIRE PPL/GRY WIRE PPL/ORG WIRE PRU PWS RED WIRE RIGHT FRONT POWER WINDOW REGULATOR SWITCH ASSEMBLY RLD RLU RRD VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Power windows circuit, without rear power window jam protection (1 of 2) -> LEFT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY

left front power window regulator motor assembly wiring diagram (4 of 4)

A/C FUSE AUTO BLK WIRE BLU WIRE CONTROL CIRCUIT DOWN DRIVER SIDE AUTO SWITCH DRIVER SIDE DOWN SWITCH DRIVER SIDE UP SWITCH FA (LEFT SIDE OF DASH) FC (RIGHT KICK PANEL) FRONT PASSENGER SIDE CONTROL SWITCH FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH) LEFT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY LEFT REAR SIDE CONTROL SWITCH LIN LT GRN WIRE P/W (FR) FUSE P/W (RL) FUSE P/W (RR) FUSE P/W F/L PNK WIRE POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY PPL/GRN WIRE PPL/GRY WIRE RED WIRE RIGHT FRONT POWER WINDOW REGULATOR SWITCH ASSEMBLY RIGHT REAR SIDE CONTROL SWITCH VIO WIRE WHT WIRE WHT/BLK WIRE WINDOW LOCK SWITCH

Go to component -> Power windows circuit, with rear power window jam protection (1 of 3) -> LEFT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY
