Toyota Highlander III (2013-2016) intermittent timing switch Wiring diagram
This page shows the only wiring diagram for the component.intermittent timing switch, which is found in the car Toyota Highlander III (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram intermittent timing switch (1 of 1)
30 32 17 39 25 PNK WIRE
BLK WIRE
BLU WIRE
BRN WIRE
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DRIVING SUPPORT ECU (RIGHT SIDE OF DASH)
ENGINE ROOM R/B 1 (LEFT SIDE OF ENGINE COMPT)
EXCEPT HYBRID
FAST
FB (UNDER FRONT OF CENTER CONSOLE)
FD (LEFT CENTER OF DASH)
FE (RIGHT CENTER OF DASH)
FR WIPER FUSE
FRONT WIPER SWITCH
FUSE
GRN WIRE
GROUND J/C 1 (LEFT FRONT CORNER OF ENGINE COMPT)
GROUND J/C 2 (LEFT FRONT CORNER OF ENGINE COMPT)
GROUND J/C 5 (RIGHT FRONT OF ENGINE COMPT)
GRY WIRE
HOT W/
INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH)
INT LO HI
INTERMITTENT TIMING SWITCH
J/C 1 (LEFT SIDE OF DASH)
LEVEL WARNING SWITCH ASSEMBLY (IN WASHER FLUID RESERVOIR)
LO HI
LT BLU WIRE
LT GRN WIRE
METER FUSE
MIST OFF
MIST OFF INT
OFF ON INT
PNK WIRE
PPL
PPL EW
PPL/BLK WIRE
PPL/GRN WIRE
PPL/PNK WIRE
PPL/PNK WR WIRE
REAR WIPER MOTOR (CENTER OF BACK DOOR)
REAR WIPER SWITCH
RED WIRE
RR WIPER
SLOW
W/O DYNAMIC RADAR CRUISE CONTROL
WASHER FUSE
WASHER SWITCH
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WASHER MOTOR, PUMP ASSEMBLY (IN WASHER FLUID RESERVOIR)
WINDSHIELD WIPER MOTOR (LEFT REAR OF ENGINE COMPT)
WINDSHIELD WIPER RELAY
WINDSHIELD WIPER SWITCH ASSEMBLY
WIPER RELAY
WIPER-S FUSE
XA (LEFT SIDE OF BACK DOOR)
YEL WIRE
Go to component -> Wiper/washer circuit -> INTERMITTENT TIMING SWITCH
