Toyota Highlander III (2013-2016) ib vib gib Wiring diagram
This page shows the only wiring diagram for the component.ib vib gib, which is found in the car Toyota Highlander III (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ib vib gib (1 of 1)
15 9 8 14 13 11 10 12 29 30 23 22 21 20 MJ RV FD
20 21 30 37 26 MTH- MTH+ HSDN REQ- REQ+
28 29 CLK- CLK+
34 33 HTM+ HTM-
ACCELERATOR PEDAL SENSOR (ON ACCELERATOR PEDAL BRACKET)
BLK WIRE
BLU WIRE
BRN WIRE
CAN I/F I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
CURRENT SENSOR
DISPLAY DRIVER
ECON
ENERGIZED INSTRUMENT PANEL J/B METER FUSE (BEHIND LEFT END OF DASH)
FB (UNDER FRONT OF CENTER CONSOLE)
FD (LEFT CENTER OF DASH)
GRN WIRE
HEATER SWITCH ASSEMBLY ECO MODE
HOT W/
IB VIB GIB
IDH
IGCT
J/C 4 (RIGHT SIDE OF DASH)
LT BLU WIRE
LT GRN WIRE
MAIN RELAY
MC (LEFT REAR QUARTERPANEL)
ORG/ WIRE
PNK WIRE
POWER MANAGEMENT CONTROL ECU (LEFT END OF DASH)
PRECHARGE RELAY
RED WIRE
SKID CONTROL ECU (BEHIND RIGHT SIDE OF DASH)
SPEAKER
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> 3.5l hybrid, a/t circuit (4 of 4) -> IB VIB GIB
