Toyota Highlander III (2013-2016) gnd rear window defogger ig+ switch lin 1 Wiring diagram
This page shows the only wiring diagram for the component.gnd rear window defogger ig+ switch lin 1, which is found in the car Toyota Highlander III (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram gnd rear window defogger ig+ switch lin 1 (1 of 1)
2.7L, W/O MEMORY
A/C AMPLIFIER ASSEMBLY (BEHIND RIGHT SIDE OF DASH)
A/C CONTROL ASSEMBLY
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DIODE (MIRROR HEATER) (LEFT SIDE OF DASH)
DOOR GLASS)
ECU-IG FUSE
ENGINE COMPT)
ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT)
ENGINE ROOM R/B 1 (LEFT SIDE OF
EXCEPT HYBRID W/0 GLASS HATCH OPENER
FB (UNDER FRONT OF CENTER CONSOLE)
FUSE
GND REAR WINDOW DEFOGGER IG+ SWITCH LIN 1
GRY WIRE
HOT AT ALL TIMES
HYBRID, EXCEPT HYBRID W/ GLASS HATCH OPENER
IDLE UP FUSE
INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH)
J/C 4 (RIGHT SIDE OF DASH)
LIN 1
LT BLU WIRE
MC (LEFT REAR QUARTERPANEL)
MIR HTR FUSE
NOISE FILTER (REAR WINDOW DEFOGGER, CENTER STOP LIGHT) (BASE OF LEFT "D" PILLAR)
ORG/ WIRE
PNK WIRE
RDEF
REAR WINDOW DEFOGGER (BACK
RELAY ENERGIZED
SEMICONDUCTOR IGN POWER INTEGRATION ECU RDEF DEFS
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Mirror heater & rear defogger circuit (1 of 2) -> GND REAR WINDOW DEFOGGER IG+ SWITCH LIN 1
