Toyota Highlander III (2013-2016) door memory locks, systems anti-theft systems Wiring diagram
This page shows the only wiring diagram for the component.door memory locks, systems anti-theft systems, which is found in the car Toyota Highlander III (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram door memory locks, systems anti-theft systems (1 of 1)
A/C FUSE
AIR CONDITIONING SYSTEM
ANTI-LOCK INSTRUMENT BRAKES CLUSTER SYSTEM SYSTEM
BACK OBD DOOR FUSE FUSE
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
DOOR BACK RELAY
DOOR MEMORY LOCKS, SYSTEMS ANTI-THEFT SYSTEMS
FROM
FROM ALT FUSE (DIAGRAM 1 OF 4)
FROM ENGINE ROOM J/B (DIAGRAM 1 OF 4)
FROM ENGINE ROOM R/B 1 (DIAGRAM 1 OF 4)
FUEL LOCK P/W P/W P/W P/W RELAY F/L R/L FUSE R/R FUSE F/R FUSE FUSE
FUSE
GRN WIRE
GRY WIRE
HTR FUSE
J/C 4 (RIGHT SIDE OF DASH)
LT BLU WIRE
LT GRN WIRE
MAIN BODY ECU
MEMORY SYSTEMS
METER A/BAG-IG FUSE FUSE
NAVIGATION SYSTEM SHIFT COMPUTER INTERLOCK DATA LINES SYSTEM SYSTEM
ORG/ WIRE
P/SEAT (FR) FUSE
P/SEAT F/L FUSE
PBD FUSE MIR HTR STOP INV FUSE SHADE FUSE FUSE FUSE FUSE
PNK WIRE
POWER RELAY (W/O REAR POWER WINDOW JAM PROTECTION)
PPL/GRN WIRE
PPL/ORG WIRE
PTC HTR 1 PTC HTR 2 PTC HTR 3 FUSE FUSE FUSE
RED WIRE
RR A/C FUSE
SEATS SYSTEM
SEATS, MEMORY SYSTEMS
SUPPLEMENTAL INSTRUMENT RESTRAINTS CLUSTER SYSTEM SYSTEM
TRUNK, TAILGATE, FUEL DOORS SYSTEM
VIO WIRE
W/ SMART KEY SYSTEM W/O SMART KEY SYSTEM
WARNING SYSTEMS
YEL WIRE
Go to component -> Power distribution circuit, except hybrid (4 of 4) -> DOOR MEMORY LOCKS, SYSTEMS ANTI-THEFT SYSTEMS
