Toyota Highlander III (2013-2016) corner of engine compt) ac Wiring diagram
This page shows the only wiring diagram for the component.corner of engine compt) ac, which is found in the car Toyota Highlander III (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram corner of engine compt) ac (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
CORNER OF ENGINE COMPT) AC
DOOR CONTROL SWITCH
DOOR CONTROL SWITCH ASSEMBLY
FA (LEFT SIDE OF DASH)
FB (UNDER FRONT OF CENTER CONSOLE)
GROUND J/C 2 (LEFT FRONT
GRY WIRE
LEFT POWER BACK DOOR SENSOR ASSEMBLY (LOWER LEFT SIDE OF BACK DOOR)
LT BLU WIRE
LT GRN WIRE
MC (LEFT REAR QUARTERPANEL)
ORG/ WIRE
PNK WIRE
RED WIRE
RIGHT POWER BACK DOOR SENSOR ASSEMBLY (LOWER RIGHT SIDE OF BACK DOOR)
WHT WIRE
WHT/BLK WIRE
WIRELESS DOOR LOCK BUZZER (LEFT SIDE OF ENGINE COMPT)
XA (LEFT SIDE OF BACK DOOR)
YEL WIRE
Go to component -> Back door opener circuit, with power back door (2 of 3) -> CORNER OF ENGINE COMPT) AC
