Toyota Highlander III (2013-2016) 13 22 yaw rate canh canl sensor wiring diagram
This page shows the only wiring diagram for the component.13 22 yaw rate canh canl sensor, which is found in the car Toyota Highlander III (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
13 22 yaw rate canh canl sensor wiring diagram (1 of 1)
1 2 PNK WIRE
1 31 CAN- CAN+
12 11 CANL CANH
13 22 YAW RATE CANH CANL SENSOR
25 14 2 12 CANH CANL
26 13 26 13 CANL CANH
3 2 CANH CANL
3.5L
5 6 CANL CANH
6 7 8 LIN CANH CANL
6 7 CAN+ CAN-
A/C AMPLIFIER ASSEMBLY (BEHIND RIGHT SIDE OF DASH)
A/C CONTROL ASSEMBLY
A/C CONTROL ASSEMBLY 2
AIR BAG SENSOR ASSEMBLY (UNDER FRONT OF CENTER CONSOLE)
BLK WIRE
BLU WIRE
BRAKE ACTUATOR ASSEMBLY (RIGHT REAR OF ENGINE COMPT)
BRN WIRE
CAN JUNCTION CONNECTOR 1 (LEFT CENTER OF DASH)
CANH CANL TS
CERTIFICATION ECU (W/ SMART KEY SYSTEM) (BEHIND RIGHT SIDE OF DASH)
ECM (LEFT SIDE OF ENGINE COMPT)
ECU-ACC FUSE
FUSE
GRN WIRE
GRY WIRE
HOT W/ ACC RELAY ENERGIZED
INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH)
JUNCTION CONNECTOR 3 (LEFT CENTER OF DASH)
JUNCTION CONNECTOR 4 (RIGHT SIDE OF DASH)
LANE DEPARTURE WARNING CAMERA (IF EQUIPPED) (TOP CENTER OF WINDSHIELD)
LIN
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
RLIN
STEERING LOCK ACTUATOR ASSEMBLY (ON STEERING COLUMN)
STEERING SENSOR (IN STEERING COLUMN)
TACH
TRANSMISSION CONTROL ECU ASSEMBLY (3.5L) (LEFT FRONT ENGINE COMPT)
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Computer data lines circuit, except hybrid (3 of 3) -> 13 22 YAW RATE CANH CANL SENSOR
