Courtesy lamps circuit, except hybrid for Toyota Highlander II (2007-2010)

17 21 LCTY ILE 4 25 MLRY BCTY 5 6 CNHH CANL 9 20 24 25 LSWD GCTY DCTY SWIL BACK WINDOW LOCK ASSEMBLY (TOP CENTER OF BACK DOOR) BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DIODE (LEFT COURTESY) DIODE (RIGHT COURTESY) DOME FUSE DOOR 1 FUSE ECU- IG 1 FUSE ECU-ACC FUSE ECU-B FUSE ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) ENGINE ROOM RELAY BOX G/H FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR ACC HOT IN ON OR START IGNITION KEY CYLINDER LIGHT IND INSTRUMENT PANEL J/B INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH) KEY CYLINDER LIGHT ASSEMBLY (W/O ENGINE IMMOBILISER SYSTEM) LEFT FRONT DOOR COURTESY LIGHT ASSEMBLY LEFT FRONT DOOR COURTESY LIGHT SWITCH (IN LEFT "B" PILLAR) LEFT FRONT DOOR LOCK MOTOR (REAR OF LEFT FRONT DOOR) LT BLU WIRE LT GRN WIRE MAIN BODY ECU (ON INSTRUMENT PANEL J/B) MIR LP RELAY ORG/ WIRE PCTY PNK WIRE POWER SWITCH (W/ SMART KEY SYSTEM) RCTY RED WIRE RIGHT FRONT DOOR COURTESY LIGHT ASSEMBLY RIGHT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY RIGHT REAR DOOR COURTESY LIGHT SWITCH (IN RIGHT "C" PILLAR) UN-LOCK WARNING SWITCH ASSEMBLY W/ OUTER MIRROR FOOT LIGHT WHT WIRE WHT/BLK WIRE

23 33 34 P/N CANH CANL BACK DOOR LOCK ASSEMBLY (W/ POWER BACK DOOR) (BOTTOM CENTER OF BACK DOOR) BACK DOOR LOCK ASSEMBLY (W/O POWER BACK DOOR) (BOTTOM CENTER OF BACK DOOR) BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM CTY DOOR FOOT LIGHT GAUGE 1 FUSE GRY WIRE HOT IN ON OR START INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH) LEFT MAP LIGHT SUB ASSEMBLY (W/ REAR READING LIGHT) LEFT REAR DOOR COURTESY LIGHT SWITCH ASSEMBLY (IN LEFT "C" PILLAR) LEFT VANITY LIGHT ASSEMBLY (IF EQUIPPED) LEFT VISOR ASSEMBLY (W/ VANITY LIGHT) LT GRN WIRE MAP LIGHT MRL- MRL+ MRR- MRR+ OFF ORG/ WIRE PARK/NEUTRAL POSITION SWITCH (ON TRANSMISSION) PNK WIRE RED WIRE RIGHT MAP LIGHT SUB ASSEMBLY (W/ REAR READING LIGHT) RIGHT VANITY LIGHT ASSEMBLY (IF EQUIPPED) RIGHT VISOR ASSEMBLY (W/ VANITY LIGHT) ROOF CONSOLE BOX ASSEMBLY ROOM LIGHT ASSEMBLY 1 (W/O REAR READING LIGHT) ROOM LIGHT ASSEMBLY 2 SIG VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE
