Toyota Highlander I facelift (2003-2007) Ground distribution circuit

2.4L A/C MAGNETIC CLUTCH, LOCK SENSOR AIR FUEL RATIO SENSOR (BANK 1 SENSOR 1) SHIELD BRAKE WARNING SWITCH BRN WIRE CAMSHAFT POSITION SENSOR SHIELD COMBINATION SWITCH CRANKSHAFT POSITION SENSOR SHIELD DATA LINK CONNECTOR 3 DRL 3 RELAY DRL 4 RELAY EA (AT RIGHT FRONT FENDER APRON) EB (AT RIGHT FRONT FENDER APRON) EE (AT INTAKE SIDE OF CYLINDER BLOCK) EF (AT LEFT SIDE OF CYLINDER BLOCK) EG (UNDER LEFT HEADLIGHT) EH (UNDER LEFT HEADLIGHT) ENGINE CONTROL MODULE ENGINE HOOD COURTESY SWITCH FAN 2 RELAY STARTER RELAY A/F RELAY HEATED OXYGEN SENSOR (BANK 1 SENSOR 2) SHIELD IGNITION COIL, IGNITER 1 IGNITION COIL, IGNITER 3 IGNITION COIL, IGNITER 2 IGNITION COIL, IGNITER 4 INVERTER RELAY J/C 1 J/C 2 J/C 3 J/C 4 J/C 7 (BEHIND RIGHT SIDE OF DASH) KNOCK SENSOR SHIELD LEFT FRONT FOG LIGHT LEFT FRONT TURN SIGNAL/ PARKING LIGHT LEFT HEADLIGHT (LOW BEAM) RIGHT FRONT FOG LIGHT LEFT FRONT PARKING LIGHT LEFT HEADLIGHT LOW BEAM NCA WIRE ORG/ WIRE PRESSURE SWITCH RADIATOR FAN MOTOR REAR DEFOG RELAY EFI RELAY RED WIRE RIGHT FRONT PARKING LIGHT RIGHT FRONT TURN SIGNAL/ PARKING LIGHT RIGHT HEADLIGHT LOW BEAM SKID CONTROL ECU W/ ACTUATOR W/ DRL W/O DRL WASHER LEVEL SENSOR WATER TEMPERATURE SWITCH 1 WHT/BLK WIRE

3.3L A/C MAGNETIC CLUTCH, LOCK SENSOR AIR BAG SENSOR ASSEMBLY BB (AT RIGHT CENTER PILLAR) BF (AT RIGHT REAR CORNER OF VEHICLE) BLK WIRE BLOWER CONTROL SWITCH BLOWER MOTOR CONTROL BRN WIRE CHARCOAL CANISTER ASSEMBLY YAW RATE SENSOR COMBINATION SWITCH CRANKSHAFT POSITION SENSOR SHIELD DATA LINK CONNECTOR 3 EC (REAR OF LEFT VALVE COVER) ED (ON TOP OF ENGINE) ENGINE CONTROL MODULE FRONT PASSENGER'S SEAT CONTROL SWITCH FRONT WIPER DEICER FRONT WIPER MOTOR IA (AT LEFT KICK PANEL) IGNITION COIL, IGNITER 1 IGNITION COIL, IGNITER 2 IGNITION COIL, IGNITER 4 IGNITION COIL, IGNITER 3 IGNITION COIL, IGNITER 5 IGNITION COIL, IGNITER 6 INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) J/C 18 (AT REAR OF VEHICLE) J/C 19 (AT REAR OF VEHICLE) J/C 23, 24 (BELOW RIGHT FRONT SEAT) J/C 7 (BEHIND RIGHT SIDE OF DASH) KNOCK SENSOR 1 SHIELD HEATED OXYGEN SENSOR (BANK 1 SENSOR 2) SHIELD KNOCK SENSOR 2 SHIELD LEFT VVT SENSOR SHIELD AIR FUEL RATIO SENSOR (BANK 1 SENSOR 1) SHIELD NCA WIRE OCCUPANT CLASSIFICATION ECU ORG/ WIRE REAR HEATER BLOWER MOTOR REAR HEATER BLOWER SWITCH REAR HEATER RELAY RED WIRE RELAY RIGHT REAR DOOR LOCK MOTOR, DOOR UNLOCK DETECTION SWITCH RIGHT REAR POWER WINDOW SWITCH RIGHT SEAT ENTERTAINMENT ECU RIGHT SEAT HEATER SWITCH RIGHT VVT SENSOR SHIELD STEREO POWER AMPLIFIER TO PASSENGER SIDE J/B (DIAGRAM 3 OF 4) W/O POWER SEAT W/ POWER SEAT WHT WIRE WHT/BLK WIRE WIRELESS DOOR LOCK ECU

BLK WIRE BODY ECU BRAKE PEDAL LOAD SENSING SWITCH BRN WIRE CENTER J/B (BEHIND UPPER CENTER OF DASH) CENTRE J/B (BEHIND UPPER CENTER OF DASH) POWER WINDOW MASTER SWITCH W/ ECU CIGARETTE LIGHTER COMBINATION METER DATA LINK CONNECTOR 3 DOOR LOCK CONTROL SWITCH ELECTRONICALLY CONTROLLED TRANSMISSION PATTERN SELECT SWITCH ENGINE CONTROL MODULE FROM CENTER J/B (DIAGRAM 3 OF 4) FROM INSTRUMENT PANEL J/B (DIAGRAM 2 OF 4) FRONT POWER OUTLET FRONT/REAR WIPER, WASHER SWITCH FUEL SENDER GARAGE DOOR OPENER, LEFT VANITY LIGHT GATEWAY ECU GLOVE BOX LIGHT TRAC OFF SWITCH HEATER RELAY IB (AT RIGHT DASH BRACE) IC (AT RIGHT KICK PANEL) INTERIOR LIGHT) J/C 13 (ON LEFT REAR OF VEHICLE) KEY INTERLOCK SOLENOID LEFT REMOTE CONTROL MIRROR LEFT SEAT HEATER SWITCH A/C CONTROL ASSEMBLY BLOWER RESISTOR MAIN SWITCH MULTI-DISPLAY NAVIGATION ECU ORG/ WIRE OVERHEAD J/B PASSENGER SIDE J/B (BEHIND RIGHT SIDE OF DASH) PRESSURE SWITCH RADIO, PLAYER RED WIRE REMOTE CONTROL MIRROR SWITCH RIGHT FRONT POWER WINDOW SWITCH RIGHT REMOTE CONTROL MIRROR RIGHT SEAT HEATER SWITCH RIGHT VANITY LIGHT SHIFT LOCK ECU SLIDING ROOF CONTROL ECU STEERING SENSOR TELL TALE LIGHT ASSEMBLY THEFT DETERRENT ECU THEFT DETERRENT INDICATOR LIGHT OPTION CONNECTOR 2 TO CENTER J/B (DIAGRAM 3 OF 4) TRANSPONDER KEY COMPUTER TURN SIGNAL FLASHER BODY ECU TURN SIGNAL SWITCH UNLOCK WARNING SWITCH SEAT HEATER RELAY VIO WIRE W/ 6 SPEAKER SYSTEM W/ MANUAL A/C W/ MOON- ROOF W/O MOON- ROOF WHT WIRE WHT/BLK WIRE WIRELESS DOOR LOCK BUZZER YEL WIRE

BA (AT LEFT CENTER PILLAR) BACK DOOR KEY LOCK, UNLOCK SWITCH BACK DOOR LOCK MOTOR, DOOR UNLOCK DETECTION SWITCH BC (AT LEFT SIDE OF REAR CROSSMEMBER) BE (AT LEFT SIDE OF BACK DOOR) DRIVER'S SEAT CONTROL SWITCH DRIVER'S SEAT LUMBER SUPPORT CONTROL FUEL PUMP TRAILER HITCH HIGH MOUNTED STOP LIGHT J/C 12 (ON LEFT REAR OF VEHICLE) J/C 14 J/C 21, 22 (BELOW DRIVER'S SEAT) LEFT REAR COMBINATION LIGHT LEFT REAR DOOR LOCK MOTOR, DOOR UNLOCK DETECTION SWITCH LEFT REAR POWER WINDOW SWITCH LEFT REAR SIDE MARKER LIGHT RIGHT REAR SIDE MARKER LIGHT LEFT SEAT HEATER SWITCH LICENSE PLATE LIGHT REAR INTERIOR LIGHT REAR INTERIOR LIGHT SWITCH REAR POWER OUTLET REAR WINDOW DEFOGGER RIGHT REAR COMBINATION LIGHT TOWING CONVERTER VOLTAGE INVERTER WHT/BLK WIRE
