Instrument illumination circuit for Toyota Highlander I (2001-2003)
Instrument illumination circuit
A/C CONTROL ASSEMBLY
ALT FUSE
BLK WIRE
BODY ECU (BEHIND RIGHT SIDE OF DASH)
CENTER J/B (BEHIND UPPER CENTER OF DASH)
CIGARETTE LIGHTER ILLUM ASHTRAY ILLUM
COMBINATION METER
ELECTRONIC CONTROLLED TRANSMISSION PATTERN SELECT SWITCH
FRONT WIPER DEICER, MIRROR HEATER SWITCH
FUSIBLE LINK BOX (LEFT SIDE OF ENGINE COMPT)
GLOVE BOX LIGHT
GRN WIRE
HEAD OFF TAIL
HOT AT ALL TIMES
IA (LEFT KICK PANEL)
IB (RIGHT INSTRUMENT PANEL BRACE)
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
LEFT SEAT HEATER SWITCH
LIGHT CONTROL SWITCH (PART OF COMBINATION SWITCH)
O/D MAIN SWITCH
PANEL FUSE
RADIO, PLAYER
RED WIRE
RHEOSTAT
RIGHT SEAT HEATER SWITCH
TAILLIGHT RELAY
TRACTION OFF SWITCH
WHT WIRE
